Part Number:
Status:
1202480014
Active
Overview:
Description:
Brad Passive-Signal and Safety MPIS Boxes
MPIS Micro-Change (M12) Passive Junction Box, Top Mount, 6 Ports, LED for PNP
Sensor, WSOR Cable, 10.0m Length
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
UL
Series image - Reference only
E152210
General
Product Family
Series
EU ELV
Not Relevant
Passive Distribution Boxes
120248
IP Rating
Overview
Product Name
UPC
IP67
EU RoHS
China RoHS
Brad Passive-Signal and Safety MPIS Boxes
MPIS
889056329668
Compliant with
Exemption 6(c)
REACH SVHC
Not Reviewed
Halogen-Free
Status
Physical
Bus I/O
N/A
Straight
10.0m
10.0m
N/A
Cable Connector Orientation
Cable Length
Home Run Cable Length
Home Run Connector
Home Run Interface
Keyway
Not Reviewed
For more information, please visit Contact US
China ROHS
ELV
RoHS Phthalates
50 Image
Not Relevant
Not Contained
Pigtail
A-coded
PNP Sensors
TPU
PBT
Copper Alloy
Gold
1237.510/g
Top Mount
4
LED Indicator
Material - Cable Jacket
Material - Housing
Material - Metal
Material - Plating Mating
Net Weight
Search Parts in this Series
120248 Series
Orientation
Poles
Poles (wired)
4
Ports
6
Temperature Range - Operating
Wire/Cable Type
Wiring Configuration
-25°C to +85°C
WSOR
Single I/O per Port
Electrical
Current - Maximum per Contact
Functional Wiring
12.0A per module, 4.0A per port
PNP
Voltage - Maximum
10-30V DC
Material Info
Engineering Number
BTB600P-FBW-10
1202480010-000
Reference - Drawing Numbers
Sales Drawing
