TN-G6500 Series
EN 50155 Full Gigabit Ethernet switches with up to 8 PoE ports
Features and Benefits
• 12 Gigabit ports with push-pull M12 connectors
• Isolated power with 24 to 110 VDC power supply range
1
• Complies with all EN 50155 mandatory test items
• -40 to 70°C operating temperature range
• IP67-rated housing protection
• Turbo Ring and Turbo Chain (recovery time < 50 ms @ 250 switches), and
RSTP/STP for network redundancy
• 8 IEEE 802.3at/af compliant PoE and Ethernet combo ports
• Provides up to 30 W per PoE port
Certifications
Introduction
The ToughNet TN-G6500 Series M12 managed Ethernet switches are designed for railway applications, including rolling stock and wayside
installations. The switches use M12 and other circular connectors to ensure tight, robust connections, and guarantee reliable operation in industrial
environments where vibration and shock are commonplace. The TN-G6500 Series Ethernet switches provide 12 Gigabit Ethernet M12 ports; 8 ports
support IEEE 802.3at/af compliant PoE functionality. These PoE switches are classified as power source equipment (PSE); they provide up to 30
watts of power per port, and can be used to power IEEE 802.3at/af compliant powered devices (PDs), such as IP cameras, wireless access points,
and IP phones.
The TN-G6500 Series has push-pull M12 connectors that are tailor-made for push-pull cables in order to facilitate quick installation, and also allow
M12 rotary cables to be utilized. The 24 to 110 VDC wide power input range and isolated dual-power inputs not only allow you to use the same type
of power source at different sites around the globe, but also increase the reliability of your communications system. Furthermore, the -40 to 70°C
operating temperature and IP67-rated enclosure allow deployment in harsh environments. The TN-G6512 Series Ethernet switches are compliant
with the essential sections of the EN 50155 standard, covering operating temperature, power input voltage, surge, ESD, vibration, power isolation,
and includes a model with conformal coating to ensure suitability for a variety of industrial applications.
Additional Features and Benefits
• Provides up to 30 watts per PoE port with a total power budget of
96 watts per switch
• RMON for efficient network monitoring and proactive capability
• Bandwidth management prevents unpredictable network status
• Lock port allows access by only authorized MAC addresses
• Port mirroring for online debugging
• Automatic warning by exception through email and relay output
• Line-swap fast recovery
• LLDP for automatic topology discovery in network management
software
• Configurable by web browser, Telnet/serial console, CLI, and
Windows utility
• IPv6 Ready logo awarded (IPv6 Logo Committee certified)
• DHCP Option 82 for IP address assignment with different policies
• IGMP snooping and GMRP for filtering multicast traffic
• EtherNet/IP and Modbus/TCP industrial Ethernet protocols
supported
• Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network
planning
• QoS (IEEE 802.1p/1Q and ToS/DiffServ) allows real-time traffic
classification and prioritization
• Loop protection prevents network loops
• IEEE 802.3ad, LACP for optimum bandwidth utilization
• SNMPv1/v2c/v3 for different levels of network management
• TACACS+, SNMPv3, IEEE 802.1X, HTTPS, and SSH to enhance
network security
• Panel mounting installation capability
1.
This product is suitable for rolling stock railway applications, as defined by the EN 50155 standard. For a more detailed statement, click here: www.moxa.com/
doc/specs/EN_50155_Compliance.pdf
