QS SERIES MASTER EVALUATION / DEVELOPMENT SYSTEM
SC SERIES BASIC EVALUATION / DEVELOPMENT SYSTEM
The EVAL-916-SC is a cost-effective way to
evaluate the SC Series and begin integrating
it into your own product. The kit features an
on-board encoder / decoder with buzzer and
relay outputs that allow range and
interference testing in anticipated use
environments. When you are ready to begin
development, a convenient prototyping area
with breakout headers and regulated power
supply allows for rapid testing and interface.
The most complete way to evaluate
the QS Series and then begin the
integration of it into your own
design. The kit allows for full
evaluation of the QS modules, and
speeds the development of your
own design via the included
development board. The board
demonstrates interfacing to RS232
devices and microcontrollers. A
large prototyping area with a break-
Basic Kit Includes
2 Assembled Evaluation / Proto boards
2 SC Transceiver Modules*
2 CW (SC, SC-S) or RCS (SC-PA)
Series Antennas
2 Extra RPSMA Antenna Connectors
(SC, SC-S only)
2 9V Batteries
Detailed Data Guides
FCC Part 2 + Part 15 Guidelines
out header allows for quick and easy prototyping of your device on the
development board itself. Drivers and software are included as well as source
code and system examples to speed software development and system
integration.
ORDERING INFORMATION
PART #
DESCRIPTION
QS Master Kit Includes
1 Assembled Development Board
2 QS USB Modules*
1 Software/Support CD
Detailed Manuals
Features
EVAL-916-SC-P
EVAL-916-SC-PA
EVAL-916-SC-S
SC Basic Evaluation System
SC-PA Basic Evaluation System
SC-S Basic Evaluation System
RS-232 <--> USB Interface
Integrated RS-22 Level Converter
On-Board Demo Microcontroller
User Prototyping Area
Free Technical Support
Pre-Assembled for Immediate Use
Demonstration Software Included
Sample Source Code Included
SC SERIES MASTER EVALUATION / DEVELOPMENT SYSTEM
The most complete way to evaluate the SC
Series and then begin the integration of it into
your own design. The kit allows for full
evaluation of the SC modules, and speeds the
development of your own design via the
included boardset which features an onboard
prototyping area, RS-232 interface and
breakout headers. Windows demonstration
software is included.
ORDERING INFORMATION
PART #
MDEV-USB-QS
DESCRIPTION
USB Master Development System
* Listed quantity includes those populated on demo / eval. boards.
SC Master Kit Includes
2 Assembled Development Boards
w/Prototyping Area and RS-232
4 SC Transceiver Modules*
1 Software/Support CD
2 CW (SC, SC-S) or RCS (SC-PA)
Series Antennas
2 Extra RPSMA Antenna Connectors
(SC, SC-S only)
2 9V Batteries
Detailed Manuals
Part 2 & Part 15 Guidelines
Free Technical Support
ORDERING INFORMATION
PART #
DESCRIPTION
MDEV-916-SC-P
MDEV-916-SC-PA
MDEV-916-SC-S
SC Master Development System
SC-PA Master Development System
SC-S Master Development System
