IXSH 40N60B VCES
IXST 40N60B IC25
= 600V
High Speed IGBT
=
=
75A
2.2V
VCE(sat)
Short Circuit SOA Capability
tfi typ
= 100 ns
Preliminary data
TO-247AD(IXSH)
Symbol
TestConditions
MaximumRatings
VCES
VCGR
TJ = 25°C to 150°C
600
600
V
V
(TAB)
TJ = 25°C to 150°C; RGE = 1 MW
G
C
VGES
VGEM
Continuous
Transient
±20
±30
V
V
E
TO-268 (D3) ( IXST)
IC25
IC90
ICM
TC = 25°C
75
40
A
A
A
TC = 90°C
G
(TAB)
TC = 25°C, 1 ms
150
E
SSOA
(RBSOA)
VGE= 15 V, TJ = 125°C, RG = 2.7 W
Clamped inductive load, VCC= 0.8 VCES
ICM = 80
@ 0.8 VCES
A
G = Gate
E = Emitter
TAB = Collector
tSC
(SCSOA)
VGE= 15 V, VCE = 360 V, TJ = 125°C
RG = 22 W, non repetitive
10
ms
W
PC
TC = 25°C
280
TJ
-55 ... +150
150
°C
°C
°C
Features
TJM
Tstg
• Internationalstandardpackages
• Guaranteed Short Circuit SOA
capability
-55 ... +150
Md
Mountingtorque
1.13/10 Nm/lb.in.
• Low VCE(sat)
Weight
6
g
- for low on-state conduction losses
• Highcurrenthandlingcapability
• MOS Gate turn-on
Maximumleadtemperatureforsoldering
1.6 mm (0.062 in.) from case for 10 s
300
°C
- drivesimplicity
• Fast Fall Time for switching speeds
up to 50 kHz
Symbol
TestConditions
CharacteristicValues
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Applications
• AC and DC motor speed control
• Uninterruptiblepowersupplies(UPS)
• Welding
BVCES
VGE(th)
IC = 250 mA, VGE = 0 V
600
4
V
V
IC = 4 mA, VCE = VGE
7
ICES
VCE = 0.8 • VCES
VGE = 0 V
TJ = 25°C
TJ = 125°C
25 mA
mA
1
Advantages
IGES
VCE = 0 V, VGE = ±20 V
±100 nA
2.2
• Easy to mount with 1 screw (TO-247)
(isolatedmountingscrewhole)
• High power density
VCE(sat)
IC = IC90, VGE = 15 V
V
IXYS reserves the right to change limits, test conditions, and dimensions.
© 2000 IXYS All rights reserved
98521B(7/00)
1 - 2
