HiPerFETTM
Power MOSFETs
IXFX 44N60
IXFK 44N60
VDSS = 600 V
ID25 = 44 A
RDS(on) = 130 mW
Single MOSFET Die
trr £ 250 ns
PLUS 247TM (IXFX)
Symbol
TestConditions
MaximumRatings
VDSS
VDGR
TJ = 25°C to 150°C
TJ = 25°C to 150°C; RGS = 1 MW
600
600
V
V
(TAB)
G
VGS
VGSM
Continuous
Transient
±20
±30
V
V
D
ID25
IDM
IAR
TC = 25°C
TC = 25°C, pulse width limited by TJM
TC = 25°C
44
176
44
A
A
A
TO-264 AA (IXFK)
EAR
EAS
TC = 25°C
TC = 25°C
60
3
mJ
J
G
(TAB)
D
S
dv/dt
IS £ IDM, di/dt £ 100 A/ms, VDD £ VDSS
TJ £ 150°C, RG = 2 W
5
V/ns
G = Gate
S = Source
D = Drain
TAB = Drain
PD
TJ
TC = 25°C
560
W
-55 ... +150
°C
TJM
Tstg
150
-55 ... +150
°C
°C
Features
TL
1.6 mm (0.063 in.) from case for 10 s
300
°C
• Internationalstandardpackages
• Low RDS (on) HDMOSTM process
Md
Mountingtorque
TO-264
0.4/6
Nm/lb.in.
• Ruggedpolysilicongatecellstructure
• UnclampedInductiveSwitching(UIS)
rated
Weight
PLUS 247
TO-264
6
10
g
g
• Lowpackageinductance
- easy to drive and to protect
• Fastintrinsicrectifier
Applications
• DC-DC converters
• Batterychargers
• Switched-modeandresonant-mode
powersupplies
• DC choppers
• ACmotorcontrol
Symbol
VDSS
TestConditions
CharacteristicValues
(TJ = 25°C, unless otherwise specified)
min. typ. max.
VGS = 0 V, ID = 3mA
600
V
• Temperatureandlightingcontrols
VGS(th)
IGSS
VDS = VGS, ID = 8mA
2.5
4.5 V
VGS = ±20 V, VDS = 0
±100nA
Advantages
IDSS
VDS = VDSS
VGS = 0 V
TJ = 25°C
TJ = 125°C
100 mA
2 mA
• PLUS 247TM package for clip or spring
mounting
RDS(on)
VGS = 10 V, ID = 0.5 • ID25
Note 1
130 mW
• Space savings
• Highpowerdensity
