MZC400TS60U
MZK400TS60U
PRELIMINARY
TM
Ultra-Fast Speed FRED
Fast Recovery Epitaxial Diode INT-A -PAK
Features
·
International standard package
With DBC ceramic base plate
Planar passivated chips
Short recovery time
MZC
MZK
·
·
VRRM = 600V
IFAVM = 400A
trr = 250ns
·
·
·
·
Low switching losses
Ultra-soft recovery behaviour
Industry standard package
UL recongnition pending
Benefits
·
Antiparallel diode for high frequency
switching devices
·
·
·
·
·
Increased operating efficiency
Direct mounting to heatsink
Uninterruptible power supplies (UPS)
Ultrasonic cleaners and welders
Low voltage peaks for reduced
protection circuits
Absolute Maximum Ratings
Symbol
VRSM & VRRM
IFRMS
Test Conditions
Max.
600
Units
V
A
A
A
A
A
A
A
o
TC=75 C
560
o
TC=75 C; rectangular, d=0.5
IFAVM
400
IFRM
tp<10µs; rep. rating, pulse width limited by TVJM
2185
o
TVJ=45 C; t=10ms (50 Hz),sine
IFSM
3300
t=8.3ms (60 Hz),sine
3600
o
TVJ=150 C; t=10ms (50 Hz),sine
2880
t=8.3ms (60 Hz),sine
3180
2
I t
o
TVJ=45 C; t=10ms (50 Hz),sine
2
A s
38400
39100
31100
31800
2500
2
A s
t=8.3ms (60 Hz),sine
o
TVJ=150 C; t=10ms (50 Hz),sine
2
A s
2
A s
t=8.3ms (60 Hz),sine
VISOL
PD
RMS Isolation Voltage, Any Terminal To Case, t=1 min
V
o
TC=25 C
1008
W
o
TJ
Operating Junction Temperature Range
Storage Temperature Range
-40 to +150
-40 to +125
C
TSTG
