IXFT30N60X IXFQ30N60X
IXFH30N60X
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
Gate Input Resistance
10
17
S
RGi
2.6
Ciss
Coss
Crss
2270
1610
14
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
Effective Output Capacitance
Co(er)
Co(tr)
120
375
pF
pF
Energy related
Time related
VGS = 0V
VDS = 0.8 • VDSS
td(on)
tr
td(off)
tf
21
43
58
33
ns
ns
ns
ns
Resistive Switching Times
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
V
RG = 5 (External)
Qg(on)
Qgs
56
12
28
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.25 C/W
C/W
TO-247 & TO-3P
0.25
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
IS
VGS = 0V
30
A
A
ISM
VSD
Repetitive, pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
120
1.4
V
trr
QRM
IRM
145
860
12
ns
IF = 15A, -di/dt = 100A/μs
nC
VR = 100V
A
Note 1. Pulse test, t 300s, duty cycle, d 2%.
