5SDD40H4000

型号：

5SDD40H4000

描述：

整流器器二极管[ Rectifier Diode ]

品牌：

ABB[ THE ABB GROUP ]

页数：

7 页

PDF大小：

277 K

下载PDF手册
VRSM
IF(AV)M
IF(RMS)
IFSM
=
=
=
=
=
=
4000 V
4140 A
Rectifier Diode
5SDD 40H4000
6500 A
46×103 A
VF0
0.905 V
rF
0.109
mW
Doc. No. 5SYA1176-00 March 05
· Very low on-state losses
· Optimum power handling capability
Blocking
Maximum rated values 1)
Parameter
Symbol Conditions
Value
4000
4000
Unit
V
Repetitive peak reverse voltage
VRRM
f = 50 Hz, tp = 10ms, Tj = -40...160°C
f = 5 Hz, tp = 10ms, Tj = -40...160°C
Non - repetitive peak reverse voltage VRSM
V
Characteristic values
Parameter
Symbol Conditions
IRRM VRRM, Tj = 160°C
min
typ
typ
max
100
Unit
Max. (reverse) leakage current
mA
Mechanical data
Maximum rated values 1)
Parameter
Symbol Conditions
min
max
Unit
kN
m/s2
m/s2
Mounting force
Acceleration
Acceleration
FM
45
50
55
50
a
a
Device unclamped
Device clamped
100
Characteristic values
Parameter
Symbol Conditions
min
25.5
typ
0.9
max
26.5
Unit
kg
Weight
m
Housing thickness
Surface creepage distance
Air strike distance
H
FM = 50 kN, Ta = 25 °C
mm
mm
mm
DS
Da
40
20
1) Maximum rated values indicate limits beyond which damage to the device may occur
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
5SDD 40H4000
On-state
Maximum rated values 1)
Parameter
Symbol Conditions
IF(AV)M 50 Hz, Half sine wave, TC = 85 °C
min
typ
max
4140
Unit
Max. average on-state
current
A
Max. RMS on-state current IF(RMS)
6500
46×103
A
A
Max. peak non-repetitive
surge current
IFSM
tp = 10 ms, Tj = 160°C,
VR = 0 V
Limiting load integral
I2t
10.58×106 A2s
49×103
Max. peak non-repetitive
surge current
IFSM
tp = 8.3 ms, Tj = 160°C,
VR = 0 V
A
Limiting load integral
I2t
10.02×106 A2s
Characteristic values
Parameter
Symbol Conditions
min
typ
max
1.310
0.905
0.109
Unit
V
On-state voltage
Threshold voltage
Slope resistance
VF
IF = 4000 A, Tj = 160°C
V(T0)
rT
Tj = 160°C
IT = 6000...19000 A
V
mW
Switching
Characteristic values
Parameter
Symbol Conditions
Qrr diF/dt = -30 A/µs, VR = 100 V
IFRM = 2000 A, Tj = 160°C
min
typ
max
Unit
4600
mAs
Recovery charge
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1176-00 March 05
page 2 of 7
5SDD 40H4000
Thermal
Maximum rated values 1)
Parameter
Symbol Conditions
min
typ
typ
max
Unit
Operating junction
temperature range
Tvj
-40
160
°C
Storage temperature range Tstg
Characteristic values
Parameter
-40
160
°C
Symbol Conditions
min
max
Unit
Thermal resistance junction Rth(j-c)
to case
Double-side cooled
Fm = 45...55 kN
8
K/kW
Rth(j-c)A Anode-side cooled
Fm = 45...55 kN
14.5
18.0
2.5
K/kW
K/kW
K/kW
K/kW
Rth(j-c)C Cathode-side cooled
Fm = 45...55 kN
Thermal resistance case to Rth(c-h)
heatsink
Double-side cooled
Fm = 45...55 kN
Rth(c-h)
Single-side cooled
Fm = 45...55 kN
5.0
Analytical function for transient thermal
impedance:
n
-t/ti
Z
(t) = R (1-e )
å
th(j-c)
th i
i=1
i
1
2
3
4
Rth i(K/kW)
4.533
0.4406
2.255
0.1045
0.868
0.0092
0.345
0.0022
ti(s)
Fig. 1 Transient thermal impedance junction-to-
case.
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1176-00 March 05
page 3 of 7
5SDD 40H4000
20000
18000
16000
14000
12000
10000
8000
6000
4000
2000
0
160 °C
Tj
= 25 °C
0
1
2
3
4
V F
( V )
Fig. 2 Max. on-state characteristics.
50
40
30
20
10
0
100
20
i2dt
80
60
40
20
15
10
5
VR = 0 V
VR 0.5 VRRM
£
I FSM
0
1
10
100
1
10
100
t ( ms )
Number n of cycles at 50 Hz
Fig. 3 Surge forward current vs. pulse length. Half
Fig. 4 Surge forward current vs. number of pulses.
sine wave, single pulse, VR = 0 V
Half sine wave, VR = 0 V
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1176-00 March 05
page 4 of 7
5SDD 40H4000
10000
9000
8000
7000
6000
5000
4000
3000
2000
1000
0
10000
9000
8000
7000
6000
5000
4000
3000
2000
1000
0
= 60°
120° 180°
y
90° 120°
= 30° 60°
180°
270°
y
DC
DC
0
1000
2000
3000
4000
IFAV
5000
( A )
0
1000
2000
3000
4000
5000
I FAV ( A )
Fig. 5 Forward power loss vs. average forward
Fig. 6 Forward power loss vs. average forward
current, sine waveform, f = 50 Hz
current, square waveform, f = 50 Hz
160
140
120
100
80
160
140
120
100
80
DC
DC
270°
= 30° 60°
90°
3000
180°
5000
= 60°
120°
3000
180°
120°
y
y
60
60
0
1000
2000
4000
IFAV
5000
0
1000
2000
4000
IFAV
( A )
( A )
Fig. 7 Max. case temperature vs aver. forward
Fig. 8 Max. case temperature vs aver. forward
current, sine waveform, f = 50 Hz
current, square waveform, f = 50 Hz
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1176-00 March 05
page 5 of 7
5SDD 40H4000
500
400
300
200
100
7000
6000
5000
4000
3000
2000
maximum
average
minimum
max.
avg.
minimum
0
20
40
60
0
20
40
- di F/dt (A/µs)
60
- di F/dt (A/µs)
Fig. 9 Reverse recovery charge vs. dIF/dt,
IF = 2000 A, VR = 100 V, Tj = Tjmax, limit
values
Fig. 10 Peak reverse recovery current vs. diF/dt,
IF = 2000 A, VR = 100 V, Tj = Tjmax, limit
values
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
Doc. No. 5SYA1176-00 March 05
page 6 of 7
5SDD 40H4000
Fig. 11 Outline drawing. All dimensions are in millimeters and represent nominal values unless stated otherwise.
Related application notes:
Doc. Nr
Titel
5SYA 2020
5SYA 2029
5SYA 2036
Design of RC-Snubbers for Phase Control Applications
Designing Large Rectifiers with High Power Diodes
Recommendations regarding mechanical clamping of Press Pack High Power Semiconductors
Please refer to http://www.abb.com/semiconductors for actual versions.
ABB Switzerland Ltd, Semiconductors reserves the right to change specifications without notice.
ABB Switzerland Ltd
Semiconductors
Doc. No. 5SYA1176-00 March 05
Fabrikstrasse 3
CH-5600 Lenzburg, Switzerland
Telephone +41 (0)58 586 1419
Fax
+41 (0)58 586 1306
Email
Internet
abbsem@ch.abb.com
www.abb.com/semiconductors
