NX8340MD-CC
ELECTRO-OPTICAL CHARACTERISTICS (TC= 0 to +75ºC, BOL, unless otherwise specified)
PARAMETER
Optical Output Power
Peak Emission Wavelength
Side Mode Suppression Ratio
Monitor Current
SYMBOL
CONDITIONS
MIN.
TYP.
MAX.
UNIT
dBm
nm
dB
Pop
*1
−4
−1
λp
CW, Pf = Pop
CW, Pf = Pop
1 290
30
1 330
SMSR
Im
ID
γ
Pf = Pop, VR = 1.5 V
VR = 1.5 V
*1
50
μA
Monitor Dark Current
Tracking Error
500
1.0
nA
Im = const. (Pf = Pop)
−1.0
dB
Driver Power Supply Voltage
Driver Power Supply Current
VCC
ICC
*1
*1
4.75
5.0
5.5
V
250
mA
Bias Set Voltage
Vb
Vm
*1
*1
1.7
1.0
0.2
2.15
1.2
V
V
V
Modulation Set Voltage
Data Input Voltage
DIN, DINB
Differential input, AC-coupled
1.6
Thermistor Resistance
B Constant
R
B
TC = 25°C, Non-operation
9.5
10.0
10.5
kΩ
3 350
3 450
3 550
K
Eye Mask Margin
Extinction Ratio
MASK
ER
Ex = 7 dB, Back to back
*1
*1
*1
5
6
%
dB
dB
dB
Dispersion Penalty
DP
BER = 10−12, 40 ps/nm, SMF
With master pigtail
1
−
Connector Repeatability
−1.0
1.0
(Applicable to SC receptacle)
*1 9.95/10.66 Gb/s, PRBS 231−1, NRZ, Duty Cycle = 50%
Life Support Applications
These NEC products are not intended for use in life support devices, appliances, or systems where the malfunction of these products can reasonably be expected
to result in personal injury. The customers of CEL using or selling these products for use in such applications do so at their own risk and agree to fully indemnify
CEL for all damages resulting from such improper use or sale.
