IXFR 34N80
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
ISOPLUS247OUTLINE
VDS = 10 V; ID = IT
Notes 2, 3
20
35
S
Ciss
Coss
Crss
7500
920
pF
pF
pF
VGS = 0 V, VDS = 25 V, f = 1 MHz
220
td(on)
tr
td(off)
tf
45
45
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 VDSS, ID = IT
RG = 1 Ω (External), Notes 2, 3
100
40
Qg(on)
Qgs
270
60
nC
nC
1 Gate, 2 Drain (Collector)
3 Source (Emitter)
4 no connection
VGS = 10 V, VDS = 0.5 VDSS, ID = IT
Notes 2, 3
Qgd
140
nC
Dim.
Millimeter
Inches
Min.
Max. Min. Max.
RthJC
RthCK
0.30 K/W
K/W
A
A1
A2
4.83
2.29
1.91
5.21
2.54
2.16
.190 .205
.090 .100
.075 .085
0.15
b
b1
b2
1.14
1.91
2.92
1.40
2.13
3.12
.045 .055
.075 .084
.115 .123
Source-DrainDiode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
C
D
E
0.61
20.80 21.34
15.75 16.13
0.80
.024 .031
.819 .840
.620 .635
Symbol
TestConditions
e
L
L1
5.45 BSC
19.81 20.32
.215 BSC
.780 .800
.150 .170
IS
VGS = 0 V
34
136
1.5
A
A
V
3.81
4.32
Q
R
5.59
4.32
6.20
4.83
.220 .244
.170 .190
ISM
VSD
Repetitive; Note 1
IF = IT, VGS = 0 V, Notes 2, 3
trr
250 ns
See IXFN 34N80 data sheet for
charactericcurves.
QRM
IRM
1.4
10
µC
IF = IT, -di/dt = 100 A/µs, VR = 100 V
A
Note: 1. Pulse width limited by TJM
2. Pulse test, t ≤ 300 µs, duty cycle d ≤ 2 %
3. IT = 17A
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYS MOSFETS and IGBTs are covered by one or more of the following U.S. patents: 4,835,592 4,881,106
4,850,072 4,931,844
5,017,508
5,034,796
5,049,961 5,187,117 5,486,715
5,063,307 5,237,481 5,381,025
