5SDF 10H4503
On-state
Maximum rated values 1)
Parameter
Symbol Conditions
IF(AV)M Half sine wave, TC = 70 °C
min
typ
max
1100
Unit
Max. average on-state
current
A
Max. RMS on-state current IF(RMS)
1740
20×103
A
A
Max. peak non-repetitive
surge current
IFSM
tp = 10 ms, Tvj = 125°C, VR = 0 V
tp = 30 ms, Tvj = 125°C, VR = 0 V
Limiting load integral
I2t
2×106 A2s
12×103
Max. peak non-repetitive
surge current
IFSM
A
Limiting load integral
Characteristic values
Parameter
I2t
2.16×106 A2s
Symbol Conditions
min
min
typ
max
3.8
Unit
V
On-state voltage
Threshold voltage
Slope resistance
VF
IF = 2500 A, Tvj = 125°C
3.1
V(T0)
rT
Tvj = 125°C
IF = 500...2500 A
1.75
0.88
V
mW
Turn-on
Characteristic values
Parameter
Symbol Conditions
VFRM dIF/dt = 600 A/µs, Tvj = 125°C
dIF/dt = 3000 A/µs, Tvj = 125°C
typ
max
80
Unit
V
Peak forward recovery
voltage
250
V
Turn-off
Maximum rated values 1)
Parameter
Symbol Conditions
min
min
typ
typ
max
Unit
Max. decay rate of on-state di/dtcrit
current
Characteristic values
IFM = 4000 A, Tvj = 125 °C
VDC-link = 2800 V
600
A/ms
Parameter
Symbol Conditions
max
1520
5250
9.5
Unit
A
Reverse recovery current
Reverse recovery charge
Turn-off energy
IRM
Qrr
Err
IFM = 3300 A, VDC-Link = 2800 V
-dIF/dt = 600 A/µs, LCL = 300 nH
CCL = 10 µF, RCL = 0.65 W,
µC
J
Tvj = 125°C, DCL = 5SDF 10H4503
