LYU5000
Ultra Brightness LED Lamp
■ Absolute Maximum Ratings
(Ta=25℃)
Characteristic
Power dissipation
Symbol
Ratings
Unit
mW
mA
mA
V
PD
IF
75
Forward Current
30
100
*1Peak Forward Current
Reverse Voltage
IFP
VR
5
Operating Temperature
Storage Temperature
*2Soldering Temperature
Topr
Tstg
Tsol
-30 ∼ +85
-40 ∼ +100
℃
℃
260℃ for 3 seconds
*1.Duty ratio = 1/16, Pulse width = 0.1ms
*2.Keep the distance more than 2.0mm from PCB to the bottom of LED package
■ Electrical – Optical Characteristics
(Ta=25℃)
Characteristic
Forward Voltage
Dominant Wavelength
Spectrum Bandwidth
Reverse Current
Symbol
Test Condition
IF= 20mA
IF= 20mA
IF= 20mA
VR=5V
Min.
Typ. Max.
Unit
V
VF
λP
-
-
-
-
-
2.1
592
15
2.7
-
nm
nm
uA
Δλ
IR
-
-
10
-
*3Half Angle
θ1/2
IF= 20mA
±10
deg
*3. θ1/2 is the off-axis angle where the luminous intensity is 1/2 the peak intensity
Different and Better
2/6
