Part Number:
2.0x1.25mm SMD CHIP LED LAMP
XZMG54W
www.SunLED.com
ꢁ Recommended Soldering Pattern (Units: mm ; Tolerance: ± 0.1)
ꢁ Tape Specification (Units : mm)
Remarks:
If special sorting is required (e.g. binning based on forward voltage, luminous intensity, or wavelength), the typical
accuracy of the sorting process is as follows:
1. Wavelength: +/-1nm
2. Luminous Intensity: +/-15%
3. Forward Voltage: +/-0.1V
Note: Accuracy may depend on the sorting parameters.
Published Date : MAY 11,2005
Drawing No : XDSA1259
V4
Checked : B.L.LIU
P.3/3
