IXFE 23N100
IXFE 24N100
Symbol
TestConditions
Characteristic Values
Min. Typ. Max.
ISOPLUS-227 B
(TJ = 25°C, unless otherwise specified)
gfs
VDS = 10 V; ID = IT, Note 2
15
22
S
Ciss
Coss
Crss
7000
750
260
pF
pF
pF
VGS = 0 V, VDS = 25 V, f = 1 MHz
td(on)
tr
td(off)
tf
35
35
75
21
ns
ns
ns
ns
VGS = 10 V, VDS = 0.5 • VDSS, ID = IT
RG = 1 Ω (External),
Qg(on)
Qgs
Qgd
250
55
135
nC
nC
nC
VGS = 10 V, VDS = 0.5 • VDSS, ID = IT
RthJC
RthCK
0.25
K/W
K/W
0.07
Source-DrainDiode
(TJ = 25°C, unless otherwise specified)
Characteristic Values
Min. Typ. Max.
Symbol
IS
TestConditions
VGS = 0
24N100
23N100
24
23
A
A
ISM
Repetitive;
24N100
23N100
96
92
A
A
pulse width limited by TJM
VSD
IF = I , VGS = 0 V,
1.5
V
PulsSe test, t ≤ 300 µs, duty cycle d ≤ 2 %
trr
250
n s
µC
A
QRM
IRM
IF = IS, -di/dt = 100 A/µs, VR = 100 V
1.0
8
Please see IXFN24N100 data
sheet for characteristic curves.
Notes: 1. Pulse width limited by TJM.
2. Pulse test, t ≤ 300 ms, duty cycle d ≤ 2%.
3. ITTest current:
24N100: I = 12 A
23N100: ITT = 11.5 A
IXYS reserves the right to change limits, test conditions, and dimensions.
