SZA45C-12
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, CA 90638
Phone: (562) 404-7855 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
Solid State
DESIGNER’S DATA SHEET
1 mA / 12 kVolts
High Voltage Regulator
Features:
· Voltage 12 kV ± 500 V
· Current to 1mA
· Rugged – Fail Safe Construction
· Metal Envelope
· Designed for Compact High Voltage Power Supplies
· Capable of being Used at Altitude of 25000 ft.
· Shock: 100g per MIL-STD-202, Method 202
· Vibration: 10g, 10 – 500 cps
· Other Voltages Available; Consult Factory
· Replaces Victoreen M45C-12
Maximum Ratings
Symbol
Value
1.0
Units
mA
mA
ºC
IZ
IPK
Maximum Continuous Current
Peak Current
1.5
Top & Tstg
-55 to +125
Operating & Storage Temperature
Electrical Characteristics @ 25°C
Current [µA]
Nom. Voltage
[ kV ]
Test Current
[ µA ]
Tolerance
[ V ]
Regulation 1/
[ V ]
NUMBER
Min
Max
1000
SZA45C-12
12
300
±300
25
500
NOTE:
1/ Regulation is Defined as Maximum Change in Voltage from Minimum to Maximum Current.
Outline and Dimensions
Tolerances:
5.12
.XX: ±.02”
.XXX: ±.010”
CATHODE
(METAL CASE)
ISOLATOR
Ø.562
Ø.375
.25
6.50
Ø.093
(ANODE)
NOTE: All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: Z00006A
