S MT LED LAMP
P LCC–2 PACKAGE
HIGH EFFICIENCY RED
YELLOW
QTLP 6 7 0 C–2
QTLP 6 7 0 C–3
GREEN
AlGa As RED
QTLP 6 7 0 C–4
QTLP 6 7 0 C–7
PACKAGE DIMENS IONS
DES CRIP TION
The QT Optoelectronics surface mount lamps are
designed with a flat top and sides for automatic
placement equipment. They are compatible with con-
vective IR and vapor phase reflow soldering and con-
ductive epoxy attachment process.
.083 (2.1)
.067 (1.7)
.118 (3.0)
.102 (2.6)
The package size and configuration conform to the
EIA–535 BAAC standard specification for case 3528
tantalum capacitor.
.035 (.9)
.028 (.7)
.091 (2.3)
.083 (2.1)
Ø .04
(.1)
.142 (3.6)
.126 (3.2)
.134 (3.4)
.118 (3.0)
.094
(2.4)
FEATURES
■ Non-diffused package for backlighting and
coupling to light pipe
■ Low package profile
■ Low power dissipation
■ Wide viewing angle
.024 (.6)
.016 (.4)
CATHODE
ANODE FOR QTLP670C–7
.043 (1.1)
.020 (.5)
.007 (.18)
.005 (.12)
NOTE: ALL DIMENSIONS ARE IN INCHES (mm)
ABS OLUTE MAXIMUM RATINGS (T = 25° C Unless otherwise specified)
A
HER
Ye llo w
Gre e n
AlGa As Re d
6 7 0 C–7
QTLP
6 7 0 C–2
6 7 0 C–3
6 7 0 C–4
Un it s
DC forward current, IF
Operating temperature range
Storage temperature range
Lead soldering time
30
20
30
30
mA
–40° C to +85° C
–40° C to +100° C
5 seconds @ 260° C
Peak forward current1, IF
Power dissipation Pd (mW)
Reversed Voltage (VR)
160
100
5
160
100
5
160
100
5
200
100
5
mA
mW
V
Notes:
1. Measured @ f=1.0 kHz, Duty factor = 1/10
HER = High Efficiency Red
