PLCC-4 (BI-COLOR) PACKAGE
SURFACE MOUNT LED LAMP
PACKAGE DIMENSIONS
HER / PURE GREEN
QTLP670C25.7744D
0.118 (3.0)
0.102 (2.6)
0.083 (2.1)
0.067 (1.7)
0.091 (2.3)
0.083 (2.1)
0.041 (0.1)
0.035 (0.9)
0.028 (0.7)
FEATURES
3
4
• Non-diffused package excellent for
0.134 (3.4)
0.118 (3.0)
0.142 (3.6)
0.126 (3.2)
back-lighting and coupling to light pipe
• Low package profile
0.094 (2.4)
0.043 (1.1)
0.020 (0.5)
• Wide viewing angle of 120°
• Moisture proof packaging
1
2
CATHODE
0.007 (.18)
0.005 (.12)
0.067 (1.7)
0.052 (1.3)
DESCRIPTION
This bi-color surface mount lamp is designed with a flat top and
sides for automatic placement equipment. It is compatible with
convective IR and vapor phase reflow soldering and conductive
epoxy attachment process. The package size and configuration
conform to EIA-535 BAAC standard specification for case size
3528 tantalum capacitor.
NOTE:
1. All dimensions are in inches (mm).
2. Pin-out connections are on page 3.
(T = 25°C unless otherwise specified)
ABSOLUTE MAXIMUM RATINGS
A
Parameter
Operating Temperature
Storage Temperature
Symbol
TOPR
Rating
Unit
°C
-40 to +100
-40 to +100
TSTG
°C
Lead Soldering Time
TSOL
IF
260 for 5 sec
30
°C
Continuous Forward Current
Peak Forward Current
mA
IF
160
mA
(f = 1.0 KHz, Duty Factor = 1/10)
Reverse Voltage (IR = 10 µA)
Power Dissipation
VR
PD
5
V
100
mW
(TA =25°C)
ELECTRICAL / OPTICAL CHARACTERISTICS
Part Number
QTLP670C25.7744D
Condition
IF = 20 mA
Luminous Intensity (mcd)
Red - Cat 17 & 18
Green - Cat 15 & 16
Forward Voltage (V)
Maximum
4 - 8, 6.5 - 13
1.5 - 3.0, 2.5 - 5.0
IF = 20 mA
IF = 20 mA
2.8 / 2.8
2.0 / 2.0
Typical
Wavelength (nm)
Peak
635 / 555
628 / 560
45 / 22
120
Dominant
Spectral Line Half Width (nm)
Viewing Angle (°)
IF = 20 mA
IF = 20 mA
1 of 3
6/2/00
300062A
