IXSK 80N60B
IXSX 80N60B
VCES = 600 V
IC25 = 160 A
VCE(sat) = 2.5 V
High Current IGBT
Short Circuit SOA Capability
Symbol
TestConditions
Maximum Ratings
PLUS247TM
(IXSX)
VCES
VCGR
TJ = 25°C to 150°C
TJ = 25°C to 150°C; RGS = 1 MΩ
600
600
V
V
VCES
VGEM
Continuous
Transient
±20
±30
V
V
(TAB)
G
C
E
TO-264 AA
(IXSK)
IC25
IC90
IL(RMS)
ICM
TC = 25°C
TC = 90°C
TC = 90°C
TC = 25°C, 1 ms
(silicon chip capability)
(silicon chip capability)
(silicon chip capability)
160
80
75
A
A
A
A
300
SSOA
(RBSOA)
VGE = 15 V, TVJ = 125°C, RG = 5 Ω
Clamped inductive load
ICM = 160
@ 0.8 VCES
A
G
(TAB)
C
E
tsc
SCSOA
VGE = 15 V, VCE = 0.6 VCES, TJ = 125°C
RG = 5 Ω, non-repetitive
10
µs
G = Gate
C = Collector
E = Emitter
TAB = Collector
PC
TC = 25°C
500
W
TJ
TJM
Tstg
-55 ... +150
150
-55 ... +150
°C
°C
°C
Features
! International standard packages
! Very high current, fast switching IGBT
! Low VCE(sat)
- for minimum on-state conduction
losses
! MOS Gate turn-on
- drive simplicity
TL
1.6 mm (0.063 in.) from case for 10 s
300
°C
Md
Mountingtorque
TO-264
0.4/6 Nm/lb.in.
Weight
PLUS 247
TO-264
6
10
g
g
Applications
!
AC motor speed control
Symbol
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
!
DC servo and robot drives
!
min. typ. max.
DC choppers
!
BVCES
VGE(th)
IC = 500 µA, VGE = 0 V
600
4
V
V
Uninterruptible power supplies (UPS)
!
Switch-mode and resonant-mode
IC = 8 mA, VCE = VGE
8
power supplies
ICES
VCE = VCES
VGE = 0 V
TJ = 25°C
TJ = 125°C
200
2
µA
mA
Advantages
PLUS 247TM package for clip or spring
!
mounting
IGES
VCE = 0 V, VGE = ±20 V
±200
nA
V
!
Space savings
VCE(sat)
IC = IC90, VGE = 15 V
2.5
!
High power density
98721B (07/02)
© 2002 IXYS All rights reserved
