2W005G THRU 2W10G
GLASS PASSIVATED SINGLE-PHASE BRIDGE RECTIFIER
Reverse Voltage - 50 to 1000 Volts Forward Current - 2.0 Amperes
Case Style WOG
FEATURES
♦ Plastic package has Underwriters Laboratory Flammability
Recognition 94V-0
0.388 (9.86)
0.348 (8.84)
♦ This series is UL listed under the Recognized Component
Index, file number E54214
0.220 (5.6)
0.160 (4.1)
♦ Glass passivated chip junctions
♦ High case dielectric strength
1.0
(25.4)
MIN.
♦ Typical I less than 0.5µA
R
♦ High surge current capability
♦ Ideal for printed circuit boards
♦ High temperature soldering guaranteed:
260°C for 10 seconds, 0.375" (9.5mm) lead length,
5lbs. (2.3kg) tension
0.032 (0.81)
0.028 (0.71)
0.060 (1.52)
0.020 (0.51)
0.220 (5.6)
0.180 (4.6)
0.348 (8.84)
0.308 (7.82)
MECHANICAL DATA
Case: Molded plastic body over passivated junctions
Terminals: Plated leads, solderable per MIL-STD-750,
Method 2026
0.220 (5.6)
0.180 (4.6)
Dimensions in inches and (millimeters)
Mounting Position: Any
Weight: 0.04 ounce, 1.1 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
2W
2W
2W
2W
2W
2W
2W
SYMBOLS 005G
01G
02G
04G
06G
08G
10G UNITS
Maximum repetitive peak reverse voltage
Maximum RMS voltage
VRRM
VRMS
VDC
50
35
50
100
70
200
140
200
400
280
400
600
420
600
800
560
800
1000 Volts
700 Volts
1000 Volts
Maximum DC blocking voltage
100
Maximum average forward rectified current
0.375" (9.5mm) lead length (SEE FIG. 1)
I(AV)
2.0
Amps
Peak forward surge current single sine-wave
superimposed on rated load (JEDEC Method)
IFSM
I2t
60.0
15.0
1.1
Amps
A2sec
Volts
Rating for fusing (t<8.3ms)
Maximum instantaneous forward voltage drop
per leg at 2.0 Amperes
VF
Maximum DC reverse current at rated
DC blocking voltage per leg
TA=25°C
TA=125°C
5.0
500.0
IR
µA
pF
Typical junction capacitance per leg (NOTE 1)
Typical thermal resistance per leg (NOTE 2)
CJ
40.0
20.0
RΘJA
RΘJL
40.0
15.0
°C/W
Operating junction temperature range
Storage temperature range
TJ
-55 to + 150
-55 to +150
°C
°C
TSTG
NOTES:
(1) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
(2) Thermal resistance from junction to ambient and from junction to lead at 0.375" (9.5mm) lead length for P.C.B. mounting
