BZX84C2V4W - BZX84C39W
200mW SURFACE MOUNT ZENER DIODE
Features
·
·
·
·
Planar Die Construction
200mW Power Dissipation
Zener Voltages from 2.4V - 39V
Ultra-Small Surface Mount Package
SOT-323
A
Dim
A
Min
0.25
1.15
2.00
Max
0.40
1.35
2.20
B
C
B
C
Mechanical Data
D
0.65 Nominal
·
·
·
·
Case: SOT-323, Molded Plastic
Case material - UL Flammability Rating 94V-0
Moisture sensitivity: Level 1 per J-STD-020A
Terminals: Solderable per MIL-STD-202,
Method 208
Polarity: See Diagram
Marking: Marking Code (See Page 2)
Weight: 0.006 grams (approx.)
G
H
E
0.30
1.20
1.80
0.0
0.40
1.40
2.20
0.10
1.00
0.40
0.18
8°
G
H
K
J
M
J
L
D
F
·
·
·
K
0.90
0.25
0.10
0°
L
M
a
All Dimensions in mm
@ TA = 25°C unless otherwise specified
Maximum Ratings
Characteristic
Symbol
VF
Value
0.9
Unit
V
Forward Voltage
@ IF = 10mA
Pd
Power Dissipation (Note 1)
200
mW
K/W
°C
RqJA
Thermal Resistance, Junction to Ambient Air (Note 1)
Operating and Storage Temperature Range
625
Tj, TSTG
-65 to +150
Ordering Information (Note 4)
Device
Packaging
Shipping
(Type Number)-7*
SOT-323
3000/Tape & Reel
* Add “-7” to the appropriate type number in Table 1 from Sheet 2 example: 6.2V Zener = BZX84C6V2W-7.
Notes: 1. Mounted on FR4 PC Board with recommended pad layout which can be found on our website
at http://www.diodes.com/datasheets/ap02001.pdf.
2. Short duration test pulse used to minimize self-heating effect.
3. f = 1KHz.
4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
DS30066 Rev. 7 - 2
1 of 3
BZX84C2V4W - BZX84C39W
www.diodes.com
