Amplifier
The content of this specification may change without notification 8/01/09
Amplifier
P/N: JXWBLA-T-950-2150-22
Parameter
Frequency Range
Gain
Unit
MHz
dB
Minimum
950
Typical
24
Maximum
2150
26
22
Gain Flatness
P1dB
IP3
dB
2
dBm
dBm
dB
24(950-1500MHz); 22(1500-2150MHz)
34
Noise Figure
5
VSWR
1:15
50
12.0
235
1:1.75
Input/Output Impedance
DC Power Supply
Supply Current
Operating Temperature
Connector
Ω
V
mA
°C
11.4
0
12.6
250
60
SMA-Female
60x50x22
0.125 Around
Dimension (excluding SMA)
Net Weight
mm
Kg
Outline Drawing
