Amplifier
The content of this specification may change without notification 8/01/09
Amplifier
P/N: JXWBLA-T-3600-40-200
Frequency Range(GHz)
Bandwidth(GHz)
3.5
±0.1
Gain(dB)
40 min
25 min
4.5
1.7/1.7
+12/ 380
SMA-Female
-40 ~+70
-55 ~+80
Pout@1dB(dBm)
Noise Figure(dB)
VSWR In/Out
DC Supply/Current(V/ mA)
Connector
Operating Temperature(°C)
Storage Temperature(°C)
Outline Drawing (Size: mm)
For current data sheets, please contact: sales@aacix.com
188 Technology Drive, Unit H, Irvine, CA 92618
1
Tel: 949-453-9888 Fax: 949-453-8889 Email: sales@aacix.com
