3dB Directional 90°Coupler
The content of this specification may change without notification 8/01/09
3dB Directional 90° Coupler
P/N: JXWBOH-T-2.4-6
Frequency Range(GHz)
Insertion Loss(dB)
Isolation(dB)
2.4-6
0.6 max
20 min
VSWR
1.4 max
50
2 max
SMA-Female
-40 ~ +80
-55 ~ +85
Impedance(Ohm)
Power Handling(W)
Connector
Operating Temperature(°C)
Storage Temperature(°C)
Outline Drawing (Size: mm)
For current data sheets, please contact: sales@aacix.com
188 Technology Drive, Unit H, Irvine, CA 92618
1
Tel: 949-453-9888 Fax: 949-453-8889 Email: sales@aacix.com
American Accurate Components, Inc.
