The VTX-5783B pulsed-coupled cavity TWT covers 8.9 GHz to 9.4 GHz with 50 kW peak output power,
2.5 % duty cycle. This device has a non-intercepting grid pulsed and single stage depressed collector to achieve
48 dB gain.
Custom configurations are also available. These variations in the performance and configuration include: cooling
method (affects average power level), mechanical configuration, electrical and RF connections, & multiple stage
depressed collector.
Typical Operating Parameters
Features
PARAMETER
Cathode Voltage
Cathode Current
Heater Voltage
Heater Current
Collector Voltage
Grid Bias Voltage
Grid Pulse Voltage
RF Drive Power
Pulse Width
MIN
-34
---
MAX
-32
8.5
11
UNITS
kV
a
V
A
kV
V
v
W
µsec
%
gpm
•
•
•
•
•
•
•
•
•
8.9 GHz to 9.4 GHz
50 kW PEAK OUTPUT POWER
2.5% DUTY CYCLE
NON-INTERCEPTING GRID PULSED
48 dB GAIN
SINGLE STAGE DEPRESSED COLLECTOR
FORCED LIQUID COOLED
PPM FOCUSED
9
---
20
-550
300
---
---
---
3.5
---
---
6
23
-450
450
0.75
50
2.5
---
Duty Cycle
WR 90 WAVEGUIDE, INPUT AND OUTPUT
Cooling Flow Rate
Pressure Drop
Weight
25
24
psi
lbs
inches
5 X5X 20
Dimensions
---
The values listed above represent specified limits for the product and are subject to change. The data should be used
for basic information only. Formal, controlled specifications may be obtained from CPI for use in equipment design.
