Part Number:
Status:
0987871019
Active
mox_crimp_terminals
Overview:
Description:
2.54mm (.100") Pitch Pitch MOX Plug Housing 6 Circuits, Brown
Documents:
Application Specification (PDF)
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Series
General
Product Family
Series
image - Reference only
China RoHS
ELV and RoHS
Compliant
Crimp Housings
98787
2x3 Circuits, Contact Retention Force without secondary
locking: 40N, with secondary locking: 60N
mox_crimp_terminals
EU RoHS
Comments
Overview
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Product Name
MOX
Physical
Circuits (maximum)
Circuits Detail
Color - Resin
Gender
6
6 x 0.635 mm
Brown
Male
Glow-Wire Compliant
Keying to Mating Part
Lock to Mating Part
Material - Resin
No
None
Yes
Nylon
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Number of Rows
Packaging Type
Panel Mount
2
Bag
No
Please visit the Contact Us section for any
non-product compliance questions.
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Polarized to Mating Part
Stackable
0.100 In
2.54 mm
0.100 In
2.54 mm
Yes
Search Parts in this Series
98787Series
No
Mates With
Temperature Range - Operating
-40°C to +100°C
987861011 Wire-to-Wire, 981980001 Wire-
to-Flex
Electrical
Current - Maximum per Contact
7.5A
Use With
Contact Molex
Material Info
Old Part Number
199312211
Reference - Drawing Numbers
Application Specification
Packaging Specification
Sales Drawing
AS-98787-001
PK-98787-001
SD-98787-001, SD-98787-002
