OTS-32DTR
™
Optiva Standard,
32 Duplex RS-232/422/485 Data
Serial Data Transmission
The OTS-32DTR provides for the digital
transmission of 32 Channels of Duplex Serial
Data.
ST, LC,
SC or FC
ST, LC,
SC or FC
Serial Data
In/Out
Serial Data
In/Out
System Design
Video
Audio
Data
A
L
E
R
T
A
L
E
R
T
S
S
A
L
E
R
T
A
L
E
R
T
A
L
E
R
T
A
L
E
R
T
S
S
S
S
All units come in an insert card version.
The cards can be inserted into our 16-slot,
19” rack-mountable card cage (OT-CC-16-100)
or one of our smaller Optiva™ Desktop
Card Racks (OT-DTCR Series).
T
A
T
U
S
T
A
T
U
S
T
A
T
U
S
T
A
T
U
S
T
A
T
U
S
T
A
T
U
S
Serial Data
In/Out
Serial Data
In/Out
™
™
™
™
™
™
Optiav
Optiav
Optiav
Optiav
Optiav
Optiav
The Optiva™ Desktop Card Racks can handle
one, two or four insert cards, creating
compact, mountable, stand alone systems.
The use of separate OT-DTCR enclosures
allows for future flexibility and expansion as
all cards are hot-swappable and can be used
in any enclosure. Each one of our card
housing units operate with an appropriate
power supply. See “Accessories” for power
supply specifications.
VAD Transmission
VAD Transmission
VAD Transmission
VAD Transmission
VAD Transmission
VAD Transmission
OTS-32DTR
(RS-232)
OTS-32DTR
(RS-422, RS-485)
Features
• Uncompressed Serial Data over one fiber
• TDM - Single fiber, dual wavelength
• Compatible with MDM-7000 Series for WDM and CWDM
multiplexing
Optiva™ Upgrade Path
• No EMI or RFI and no ground loops
• Stand alone or rack-mount
This system can be purchased without
an optical port as an add-on to an existing
Optiva™ system daisy-chain.
(See “Non-Optical Version” below.)
The Optiva™ bandwidth requirement
of this system is 288 Mbps.
Versions Available*
Wavelength (nm)
& Fiber
Optical
Connector
Optical Budget Range***
Transmit/Receive**
Receive/Transmit**
(dB)
(km) Form Factor
1310/1550 Multimode
OTS-32DTR-A2/A3M-XX-IC
OTS-32DRT-A3M/A2-XX-IC
OTS-32DRT-A3/A2-XX-IC
OTS-32DRT-A3D/A2-XX-IC
OTS-32DRT-A3H/A2-XX-IC
OTS-32DRT-L4/L4-XX-IC
ST, FC, LC or SC
ST, FC, LC or SC
ST, FC, LC or SC
ST, FC, LC or SC
ST, FC, LC or SC
10
12
3
IC(2 or 4-slots)
IC(2 or 4-slots)
IC(2 or 4-slots)
IC(2 or 4-slots)
1310/1550 Singlemode OTS-32DTR-A2/A3-XX-IC
20
40
60
1310/1550 SM (D)
1310/1550 SM (H)
1270-1610 SM (CWDM)
OTS-32DTR-A2/A3D-XX-IC
OTS-32DTR-A2/A3H-XX-IC
OTS-32DTR-L4/L4-XX-IC
17
25
Varies
20-70 IC(2 or 4-slots)
N/A IC(2 or 4-slots)
Non-Optical Version
OTS-32DTR-NOC-IC
OTS-32DRT-NOC-IC
N/A
N/A
Serial Data Codes - "D" indicates RS-232. For other Serial Data preferences, please use: "DJ" = RS-422; "DK" = RS-485 (2W); and "DW" = RS-485 (4W).
* Contact Opticomm for other versions available.
** XX indicates the type of optical connector. Each of ST, FC, LC or SC are available.
*** Chromatic dispersion and additional losses should be taken into account.
