THE CONNOR-WINFIELD CORP.
2111 COMPREHENSIVE DRIVE.
AURORA, IL 60505.
FAX
PHONE (630) 851-4722.
WWW.CONWIN.COM
(630) 851-5040.
P R O D U C T D A T A S H E E T
CRYSTAL CONTROLLED OSCILLATORS
PACKAGE CHARACTERISTICS
Pin Connections
TABLE 5.0
Package
Surface Mount, Non-hermetic package consisting of an FR4 substrate with
grounded metal cover.
TABLE 7.0
Function
Pin
1
Voltage Control
Ground (Case)
Output
PROCESS RECOMMENDATIONS
TABLE 6.0
7
Solder Reflow
Wash
See solder profile.
8
Ultrasonic cleaning is not recommended
14
Vcc
Notes:
Output Waveform
1) Initial calibration @ 25°C, Vc = 1.48 Vdc.
2) Frequency vs. temperature stability referenced to 25°C.
3) Inclusive of calibration, operating temperature range, supply voltage change, shock and
vibration and aging (10 years).
90%
50%
10%
4) Specifications at time of shipment after 48 hours of operation.
5) Measured @ 25°C, within 5 minutes, the unit will be within +/-0.1ppm of its reference
frequency, measured after 30 minutes of continuous operation at a stable 25°C.
6) Referenced to Fo @ 25°C, Positive Transfer Characteristic.
ENVIRONMENTAL CHARACTERISTICS
Temperature Cycle: Per MIL-STD-883, Method 1010, Condition B. -55°C to 125°C, 300 cycles, 10 minute dwell, 1 minute
transition.
Suggested Pad Layout
MECHANICAL CHARACTERI STICS
Vibration: Per MIL-STD-202, Method 204, Condition A. 10G’s peak, 10Hz to 500Hz, 15 minute cycles, 12 times each
perpendicular axis.
Shock: Per MIL-STD-202, Method 213, Condition F. 1500G’s, 1.0ms, half sine, 3 shocks per direction.
Moisture Resistance: Per MIL-STD-202, Method 106. 95% RH @ 65°C, 10 cycles 10°C to 65°C.
Test Circuit
CONTROL
POWER
VOLTAGE
SUPPLY
14
8
3.0Vdc
3.3Vdc
Keep Out Area
1
7
.830
(21.08mm)
Solder Profile
.565
(14.35mm)
Package Outline
..333300 mmaaxx
((88..338822mmmm))
Dimensional Tolerance:
±.005 (.127mm)
Specifications subject to change without notice.
Copyright 2001 Connor-Winfield all rights reserved.
a
02/19/07
Cx084
01
2
2
DATASHEET #:
PAGE
OF
REV:
DATE:
