FRONT PANEL
1. Snooze/Backlight
2. LCD
User's Guide
3. Time
4. Alarm Set
5. Down
2
6. Up
7. °C/°F
8. Alarm On/Off
9. Air Pressure
Radio Controlled Clock
and Weather Station
Model WTH100
Introduction
3
4
5
6
7
8 9
Congratulations on your purchase of the Extech WTH100 Radio Controlled Wireless Weather
Station. This device is shipped fully tested and calibrated and, with proper use, will provide years
of reliable service.
LCD DISPLAY
1. Weather Forecast/Moon Phase
2. Time
3
4
Operation
1
3. Temperature
4. Atmospheric Pressure
5. Seconds/Day of Week
GETTING STARTED
5
6
6. Time Zone
1. Remove the battery door by slightly pressing the latch upwards.
2. Insert two new AA size batteries as per indication marked on the battery compartment.
3. Close the battery door.
2
7. Signal Strength
7
8
8. Daylight Savings Time
9. Day/Month/Year/Alarm Time
9
4. Press the reset button (located on back of clock). The Radio Controlled Clock will
automatically start scanning for the radio controlled time signal.
SECONDS, DAY OF WEEK AND YEAR DISPLAY
5. The default time zone is Pacific zone. If you are in this time zone, changing is not required.
Otherwise, change to the correct time zone (Refer to ‘Setting the Time Zone’.)
The clock alternates between displaying seconds and the day of the week.
To display the year, press TIME. The year will display. Press TIME again to return do day and month or
clock will switch back automatically after 30 seconds.
Notes
In some cases, the clock may be unable to receive a signal immediately. Due to atmospheric
disturbances during the day, the best reception often occurs at night.
SETTING THE ALARM
1. With the clock in normal time display mode press
and hold ALM SET button.
The clock is susceptible to interference. Always place the clock away from devices such as TV’s and
computers. Avoid placing clock on or near a metal object.
2. Press or hold ▲ or ▼ to change hour.
3. Press ALM SET again. The minute digits will flash
4. Press or hold ▲ or ▼ to change minutes
5. Press ALM SET to save.
Do not start the clock in a moving vehicle. Avoid closed areas.
FUNCTION KEYS
6. Slide ALARM button to ON position.
and Zz appear. Your alarm is now set
TIME key:
Push to toggle from day and month to year display. Push and hold to enter time set mode.
Push to view alarm set time. Push and hold to enter alarm set mode.
Slide switch to turn alarm on or off..
Selects unit of display for temperature. Press and hold for 3 seconds for signal
reception test.
ALM SET key:
ALARM On/OFF
°C/°F key:
SETTING TIME MANUALLY
1. Remove battery for 30 seconds.
2. Press TIME until HOUR digits flash. Press or hold ▲ or ▼ to change hour
3. Press TIME. MINUTES flash. Press or hold ▲ or ▼ to change minutes.
4. Press TIME again to step through Hours > Minutes > Seconds > Year .> Month > Date>Language
(GB-FR-DE-ES-IT). Press or hold ▲ or ▼ to change.
Mb/hPA/InHg:
SNOOZE/LIGHT
Display air pressure in inches of mercury or millibars AND hectopascals.
Turns on Backlight and turns alarm off in snooze mode. Snooze interval is 4
minutes.
WEATHER FORECAST
This device forecasts the next 12 to 24 hours of weather within a 30-50 km (19-31 mile) radius based
on barometric pressure trend readings and indicated by these icons.
MOON PHASE
Moon phase is indicated by the following icons
SIGNAL STRENGTH INDICATOR
The signal indicator displays signal strength in 3 levels. Wave segment flashing means time signals are
being received. The signal quality falls into three categories:
ES
Bad Signal Quality
SETTING THE TIME ZONE
Make sure the time zone is already set to appropriate location. The default time zone is Pacific zone. If
your location is out of Pacific zone press the ▲ key to select the proper time zone. (P=Pacific
M=Mountain C=Central E=Eastern)
Acceptable
Excellent
5. Press TIME to save.
SNOOZE FUNCTIONS
1. When alarm goes off, press SNOOZE
2. Clock will snooze for 4 minutes
12/24 Hour Clock
In clock mode press ▼ to switch time display from 12 hour clock (am/pm) to 24 hour clock.
Support line (781) 890-7440
SPECIFICATIONS
Battery Operated:
Battery Life:
Pressure Range
Temperature Range
2 x AAA
Technical Support: Extension 200; E-mail: support@extech.com
Repair & Returns: Extension 210; E-mail: repair@extech.com
Product specifications subject to change without notice
Approximately 1.5 years
850 mb to 1050 mb
-10C to 50C/ +14F to 122F
For the latest version of this User Guide, Software updates, and other
up-to-the-minute product information, visit our website: www.extech.com
Extech Instruments Corporation, 285 Bear Hill Road, Waltham, MA 02451
Warranty
EXTECH INSTRUMENTS CORPORATION warrants this instrument to be free of defects in parts and workmanship for one
year from date of shipment (a six month limited warranty applies to sensors and cables). If it should become necessary to
return the instrument for service during or beyond the warranty period, contact the Customer Service Department at (781) 890-
7440 ext. 210 for authorization or visit our websifor contact information. A Return Authorization (RA) number must be issued
before any product is returned to Extech. The sender is responsible for shipping charges, freight, insurance and proper
packaging to prevent damage in transit. This warranty does not apply to defects resulting from action of the user such as
misuse, improper wiring, operation outside of specification, improper maintenance or repair, or unauthorized modification.
Extech specifically disclaims any implied warranties or merchantability or fitness for a specific purpose and will not be liable for
any direct, indirect, incidental or consequential damages. Extech's total liability is limited to repair or replacement of the
product. The warranty set forth above is inclusive and no other warranty, whether written or oral, is expressed or implied.
Copyright © 2007 Extech Instruments Corporation
All rights reserved including the right of reproduction in whole or in part in any
form.
WTH100 V1.1 11/07
