VVA-MCM-1.9G- B
BI-PHASE VOLTAGE VARIABLE ATTENUATOR
PRELIMINARY SIMULATED DATA
REV: 002, 05/28/02
MULTI-MIX PICO™ COMPONENTS MOUNTED ON MERRIMAC BOARD
• PRE-MOUNTED AND PRE-TESTED
1.93 - 1.99 GHz
45 dB ATTENUATION RANGE
• SURFACE MOUNT OR CONNECTORIZED
• LOW LOSS
•
•
GENERAL SPECIFICATIONS
Frequency Range:
Attenuation Range:
Attenuation Flatness:
Insertion Loss:
1.93 – 1.99 GHz
0 – 45 dB
0.5 dB (0 - 40 dB attenuation)
3 dB (@ 0 mA)
1.9:1
VSWR:
Impedance:
50 Ohms
Control Current:
Control Voltage:
Input 1-dB Compression Point:
0 to + 40 mA
0 to + 15 V
+ 31 dBm
Input Intercept Point (2 Tone, 3rd Order): + 41 dBm
10 µs
-55°C to 85°C
Switching Speed:
Operating Temperature:
Footprint Outline:
0.8" x 0.8"
SIMULATED PERFORMANCE CHARTS
Relative Attenuation
Relative Attenuation
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
-60.00
-70.00
0.00
-10.00
-20.00
-30.00
-40.00
-50.00
-60.00
-70.00
13.8 mA
13.9 mA
14.0 mA
14.2 mA
15.0 mA
15.8 mA
16.4 mA
17.0 mA
17.8 mA
19.0 mA
20.7 mA
23.4 mA
28.4 mA
40.0 mA
0.0 mA
8.1 mA
9.2 mA
10.0 mA
10.5 mA
11.4 mA
11.9 mA
12.3 mA
12.7 mA
13.0 mA
13.3 mA
13.4 mA
13.5 mA
13.6 mA
13.7 mA
13.8 mA
1.93
1.94
1.95
1.96
1.97
1.98
1.99
1.93
1.94
1.95
1.96
1.97
1.98
1.99
Frequency (GHz)
Frequency (GHz)
