OXCFU950
16 bit PC card / CF+ bridge to serial and USB host port
Description
Combining
performance USB Host Controller, UART and 16-
bit PC Card/Compact Flash technology, the
OXCFU950 is the ideal connectivity solution for
products that need to bridge multiple or high
data rate devices to 16-bit PC Card or Compact
Features
Oxford
Semiconductor’s
high
o
o
Compliant with USB 2.0/1.1, up to 12 Mbps
Integrated OHCI compatible host controller
and PHY
Supports USB suspend/resume
8K Byte USB data buffer
High performance UART with peak
asynchronous data rates up to 12Mbps
Deep 128-Byte receive/transmit FIFOs
Full modem interface with hardware out of
band flow control
o
o
o
Flash
interfaces
including:
Cellular
EvDO/WCDMA/HSDPA, Bluetooth 2.0 and Mobile
Digital TV modules.
o
o
This highly integrated device is backed by
certified device drivers, for a wide range of
operating
performance with reduced design cycles and
accelerated time to market.
o
Flexible clock prescalar allows for a wide
range of baud rates
systems,
to
deliver
ultimate
o
o
o
o
o
Infra-red (IrDA) receive and transmit
4 GPIOs
16-bit PC Card 8.1 and CF+ 3.0 compliant
3.3V operation with 5V Tolerant IO
Integrated EEPROM for CIS and device
configuration
The OXCFU950 is a single chip; serial and USB
host port solution for 16-bit PC Card and
Compact Flash based bridging applications. The
device incorporates Oxford Semiconductor’s high
performance, feature-rich USB host and UART
technology that deliver the industry’s fastest
throughput and unrivalled flexibility in a class
leading connectivity solution.
o
Low standby and operational power
consumption
o
o
Industrial temperature range (-40 to +85°C)
Certified device drivers for a wide range of
operating systems
Development Support
Design and evaluation of the OXCFU950 is easy
with an available evaluation kit that includes
everything needed for PC installation and
evaluation. The kit includes Oxide, an intuitive
graphical user interface development tool that
provides simple ‘point and click’ feature
selection and text box entry for fast, error free
customization with minimal software expertise.
Ordering Information
Device
OXCFU950
Development Kit
EV- OXCFU950
© 2008 Oxford Semiconductor
Web: www.oxsemi.com
July 2008, REV. 1.0
