2.0 - 8.0 GHz
SPECIFICATIONS, VZS/C-6963J2
Electrical
Environmental (Operating)
Ambient Temperature
Relative Humidity
Altitude
-10° to +40°C operating
Frequency
2.0 to 8.0 GHz
95ꢃ non-condensing
Output Power
TWT
Flange
250 W or 340 W min.
225 W or 300 W min.
O P T I O N S :
Up to 10,000 ft (3000 m) witꢁ standard
adiabatic derating of 2°ꢀ1000 ft.
• Input Isolator
(-1 dB gain)
Bandwidth
Gain
6.0 GHz
Shock and Vibration
Acoustic Noise
Designed to meet conditions normally
encountered in tꢁe laboratory
54 dB min. at rated power output;
56 dB typ. at small signal
• Remote Control
Panel
65 dBA @ 3 ft. from amplifier
RF Level Adjust
Gain Stability
0 to 20 dB continuous
Mechanical
• 115 VAC
0.25 dBꢀ24 ꢁr maꢂ.
(at constant drive and temp.)
External Step-Up
Transformer
Cooling (TWT)
Forced air witꢁ integral blower.
Rear air intake and eꢂꢁaust.
Gain Variation
Input VSWR
12.0 dB pk-pk maꢂ. over tꢁe
6.0 GHz bandwidtꢁ, typ.
RF Input Connection
RF Output Connection
RF Power Monitors
Type N female
Type N female
2.5:1 typ.
1.7:1 maꢂ. (witꢁ optional input isolator)
Type-N female, -50 dB nominal
Output VSWR
Load VSWR
2.5:1 typ.
Dimensions (W x H x D)
19 ꢂ 8.75 ꢂ 26 in.
(483 ꢂ 222 ꢂ 661 mm)
1.5:1 maꢂ. for full spec compliance;
2.0:1 maꢂ. continuous operation;
any value witꢁout damage
Weight
Safety
110 lbs (50 kg)
EN61010
Residual AM
-50 dBc below 10 kHz;
-20 [1.3 + log F (kHz)] dBc,
10 kHz to 500 kHz;
-85 dBc above 500 kHz
Phase Noise
Meets IESS-308ꢀ309 witꢁ 3 dB margin
-50 dBc typ. eꢂcluding ꢁarmonics
-3 dBc typical at lower band edge
Noise and Spurious
Harmonic Content
Primary Power
220-240 VAC 10ꢃ, single pꢁase,
47-63 Hz
Power Consumption
Inrush Current
2.6 kVA typ.
3.0 kVA maꢂ.
200ꢃ maꢂ.
