Part Number:
Status:
0985991003
Active
Description:
MOX Right Angle Airbag Header Assembly, 44 Circuits, Gold Over Nickel
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
PCB Headers
98599
Series
image - Reference only
China RoHS
Application
Product Name
Wire-to-Board
MOX
EU RoHS
Physical
Breakaway
ELV and RoHS
Compliant
No
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Circuits (Loaded)
Circuits (maximum)
Color - Resin
44
64
Black
20
No
No
No
None
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
None
Phosphor Bronze
Gold over Nickel
Polyester Alloy
2
Right Angle
0.122 In
3.10 mm
Yes
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
98599Series
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
0.063 In
1.60 mm
Tray
Mates With
98615 MOX Female Housing
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Polarized to Mating Part
Polarized to PCB
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
0.100 In
2.54 mm
Yes
Yes
Yes
Use With
PCB
-40°C to +85°C
Surface Mount
Electrical
Current - Maximum per Contact
Voltage - Maximum
6A
14V DC
Material Info
Reference - Drawing Numbers
Sales Drawing
SD-98599-006
