Zowie Technology Corporation
Switching Diode
Lead free product
1SS400G
1
2
SOD-523
MAXIMUM RATINGS
Value
90
Symbol
VRRM
Unit
Rating
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Volts
VRMS
VDC
Io
63
Volts
Volts
Amps
Maximum DC Blocking Voltage
80
Maximum Average Forward Rectified Current
0.1
Peak Forward Surge Current at 1 Sec.
IFSM
0.5
Amps
Typical junction capacitance between Terminal (NOTE 1)
Maximum Reverse Recovery Time (NOTE 2)
Maximum Operating Temperature Range
C
J
3.0
4.0
PF
TRR
ns
TJ
+125
℃
Storage Temperature Range
TSTG
-55 to +125
℃
ELECTRICAL CHARACTERISTICS (T
Characteristics
A
=25oC unless otherwise noted)
Symbol
1SS400G
Unit
Volts
Maximum lnstantaneous Forward Voltage at I
F=100mA
V
F
1.20
0.1
Maximum Average Reverse Current at V =80V
R
I
R
uAmps
NOTES : 1.Measured at 1.0MHz and applied reverse voltage of 0.5 volts.
2.Measured at applied froward current of 10mA , reverse volfage of 6.0 volts and RL = 100 ohms.
3.ESD sensitive product handling required.
REV. 1
