High Performance RFI Filters for Switching Power Supplies
G Series
UL Recognized
CSA Certified
VDE Approved
10EG1/10VG1
6EG1/6VG1
G Series
Specifications
Maximum leakage current,each line-to-ground
EG Models
The G series RFI filters are designed to provide excellent
common-mode and differential-mode attenuation for most
digital electronic equipment (particularly switching power
supplies) over the frequency range of 20kHz to 30MHz.
VG Models
1.2 mA
2.0 mA
@ 120 VAC 60 Hz:
@ 250 VAC 50 Hz:
Hipot rating (one minute):
line-to-ground
.30 mA
.50 mA
These filters are a size- and cost-effective solution for
equipment that must meet the conducted emission limits of
EN55022 Level A requirements, as well as FCC Part 15J,
Class B.
2250 VDC
1450 VDC
50/60 Hz
line-to-line
Operating frequency:
The EG models also meet the very low leakage current
requirements for VDE portable equipment as well as (120
volt) UL 544 non-patient medical equipment.
Rated voltage (max.):
Rated current:
250 VAC
6EG1/6VG1
6A
10EG1/10VG1
10A
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
Current
Frequency-MHz
Rating .01 .05 .07 .1 .15 .5
1
5
10 30
Electrical Schematics
EG1
06A
10A
6
8
19 23 25 29 48 44 43 40 40
10 15 18 42 64 65 65 60 60
6EG & 6VG Models
VG1
06A
10A
LINE
LOAD
4
5
18 21 25 30 56 55 53 45 45
10 24 37 50 72 70 70 60 60
Line-to-line in 50 ohm circuit
Current
Frequency-MHz
10EG & 10VG Models
Rating .01 .05 .07 .1 .15 .5
1
5
10 30
EG1
06A
10A
4
5
6
5
10 24 37 66 75 72 50 50
LINE
LOAD
5
26 40 65 65 60 70 70
VG1
06A
10A
4
5
7
5
7
7
26 39 67 75 68 55 55
26 39 65 60 60 70 70
Resistor location for reference only.
64
Catalog 1654001
Revised 05-07
Dimensions are in inches and
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
