IXSH20N60U1

型号：

IXSH20N60U1

描述：

低VCE （ sat）的IGBT与二极管，高速IGBT与二极管[ Low VCE(sat) IGBT with Diode, High Speed IGBT with Diode ]

品牌：

IXYS[ IXYS CORPORATION ]

页数：

6 页

PDF大小：

116 K

下载PDF手册
Not for new designs
VCES
IC25 VCE(sat)
Low VCE(sat) IGBT with Diode
High Speed IGBT with Diode
IXSH 20 N60U1
IXSH 20 N60AU1
600 V 40 A 2.5 V
600 V 40 A 3.0 V
CombiPacks
Short Circuit SOA Capability
Symbol
TestConditions
Maximum Ratings
TO-247 AD
VCES
VCGR
TJ = 25°C to 150°C
600
600
V
V
TJ = 25°C to 150°C; RGE = 1 MΩ
VGES
VGEM
Continuous
Transient
±20
±30
V
V
G
C
E
IC25
IC90
ICM
TC = 25°C
40
20
80
A
A
A
G = Gate,
E = Emitter,
C = Collector,
TAB = Collector
TC = 90°C
TC = 25°C, 1 ms
SSOA
(RBSOA)
VGE= 15 V, TJ = 125°C, RG = 82 Ω
Clamped inductive load, L = 100 µH
ICM = 40
@ 0.8 VCES
A
µs
W
Features
tSC
(SCSOA)
VGE= 15 V, VCE = 360 V, TJ = 125°C
RG = 82 Ω, non repetitive
10
●
International standard package
JEDEC TO-247 AD
High frequency IGBT with
●
PC
TC = 25°C
150
guaranteed
TJ
-55 ... +150
150
°C
°C
°C
Short Circuit SOA capability
IGBT and anti-parallel FRED in one
TJM
Tstg
●
package
-55 ... +150
2nd generation HDMOSTM process
●
Md
Mounting torque
1.13/10 Nm/lb.in.
●
Low VCE(sat)
- for low on-state conduction losses
MOS Gate turn-on
- drive simplicity
Weight
6
g
●
Maximum lead temperature for soldering
1.6 mm (0.062 in.) from case for 10 s
300
°C
Applications
Symbol
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
●
AC motor speed control
DC servo and robot drives
DC choppers
Uninterruptible power supplies (UPS)
Switch-mode and resonant-mode
power supplies
●
●
●
BVCES
VGE(th)
IC = 1.75 mA, VGE = 0 V
IC = 1.5 mA, VCE = VGE
600
3.5
V
V
●
6.5
ICES
VCE = 0.8 • VCES
VGE = 0 V
TJ = 25°C
TJ = 125°C
500 µA
mA
Advantages
8
●
Space savings (two devices in one
IGES
VCE = 0 V, VGE = ±20 V
±100 nA
package)
Easy to mount with 1 screw
(isolated mounting screw hole)
Reduces assembly time and cost
●
VCE(sat)
IC = IC90, VGE = 15 V
20N60U1
20N60AU1
2.5
3.0
V
V
●
●
High power density
91770D (4/96)
IXYSCorporation
3540 Bassett Street, Santa Clara CA 95054
Phone: 408-982-0700, Fax: 408-496-0670
IXYSSemiconductorGmbH
Edisonstr. 15, D-68623Lampertheim
Phone:+49-6206-503-0, Fax:+49-6206-503627
IXSH 20N60U1
IXSH 20N60AU1
Symbol
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
TO-247 AD Outline
gfs
IC = IC90; VCE = 10 V,
6
7
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
IC(on)
VGE = 15 V, VCE = 10 V
65
A
Cies
Coes
Cres
1800
250
45
pF
pF
pF
VCE = 25 V, VGE = 0 V, f = 1 MHz
Qg
90
40
65
120 nC
55 nC
80 nC
Qge
Qgc
IC = IC90, VGE = 15 V, VCE = 0.5 VCES
1 = Gate
2 = Collector
3 = Emitter
Tab = Collector
Inductive load, TJ = 25°C
IC = IC90, VGE = 15 V,
L = 100 µH, VCE = 0.8 VCES
RG = 39 Ω
td(on)
tri
td(off)
tfi
100
200
450
ns
ns
ns
,
Remarks: Switching times
20N60U1
ns
ns
may increase for VCE (Clamp)
> 0.8 • VCES, higher TJ or
increased RG
20N60AU1 350
Eoff
2.5
mJ
td(on)
tri
100
200
1
ns
ns
Inductive load, TJ = 125°C
IC = IC90, VGE = 15 V,
L = 100 µH
Eon
td(off)
tfi
mJ
VCE = 0.8 VCES, RG = 39 Ω
1000 ns
Remarks: Switching times
may increase for VCE (Clamp)
> 0.8 • VCES, higher TJ or
increased RG
20N60U1
20N60AU1
1000 ns
600 ns
Eoff
20N60U1
20N60AU1
9
3
mJ
5 mJ
RthJC
RthCK
0.83 K/W
K/W
0.25
Reverse Diode (FRED)
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Symbol
VF
TestConditions
IF = IC90, VGE = 0 V,
1.6
V
Pulse test, t ≤ 300 µs, duty cycle d ≤ 2 %
IRM
trr
IF = IC90, VGE = 0 V, -diF/dt = 240 A/µs
VR = 360 V
10
TJ = 125°C 150
IF = 1 A; -di/dt = 100 A/µs; VR = 30 V TJ = 25°C 35
A
ns
50 ns
RthJC
1 K/W
IXYS MOSFETs and IGBTs are covered by one of the following U.S.patents: 4,835,592 4,881,108 5,017,508 5,049,961 5,187,117 5,486,715
4,850,072 4,931,844 5,034,796 5,063,307 5,237,481 5,381,025
IXSH 20N60U1
IXSH 20N60AU1
Fig. 1 Saturation Characteristics
Fig. 2
Output Characterstics
40
30
20
10
0
70
60
50
40
30
20
10
0
VGE = 15V
TJ = 25°C
TJ = 25°C
VGE =15V
13V
11V
13V
11V
9V
7V
9V
7V
0
1
2
3
4
5
0
2
4
6
8
10 12 14 16 18 20
VCE - Volts
VCE - Volts
Fig. 3 Collector-Emitter Voltage
vs. Gate-Emitter Voltage
Fig. 4
Temperature Dependence
of Output Saturation Voltage
10
9
8
7
6
5
4
3
2
1
0
1.7
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
TJ = 25°C
VGE = 15V
I
C = 40A
IC = 40A
IC = 20A
IC = 10A
I
C = 20A
IC = 10A
8
9
10
11
12
13
14
15
-50 -25
0
25 50
75 100 125 150
VGE - Volts
TJ - Degrees C
Fig. 5 Input Admittance
Fig. 6
Temperature Dependence of
Breakdown and Threshold Volt.
1.3
1.2
1.1
1.0
0.9
0.8
0.7
40
35
30
25
20
15
10
5
VCE = 10V
BVCES
IC = 3mA
TJ = 125°C
TJ = 25°C
TJ = - 40°C
VGE(th)
IC = 1.5mA
0
5
6
7
8
9
10 11 12 13 14 15
-50 -25
0
25 50
75 100 125 150
VGE - Volts
TJ - Degrees C
IXYSCorporation
IXYSSemiconductorGmbH
3540 Bassett Street, Santa Clara CA 95054
Phone: 408-982-0700, Fax: 408-496-0670
Edisonstr. 15, D-68623Lampertheim
Phone:+49-6206-503-0, Fax:+49-6206-503627
IXSH 20N60U1
IXSH 20N60AU1
Fig.7 Turn-Off Energy per Pulse and
Fall Time on Collector Current
Fig.8 Dependence of Turn-Off Energy
Per Pulse and Fall Time on RG
600
500
400
300
200
100
0
6
5
4
3
2
1
0
600
500
400
300
200
100
0
6
5
4
3
2
1
0
TJ = 125°C
TJ = 125°C
C = 20A
RG = 22Ω
I
tfi (-A)
tfi (-A)
hi-speed
hi-speed
Eoff (-A)
hi-speed
Eoff (-A)
hi-speed
0
10
20
30
40
0
20
40
60
Rg - Ohms
80
100
120
IC - Amperes
Fig.9 Gate Charge Characteristic Curve
Fig.10
Turn-Off Safe Operating Area
15
12
9
100
10
IC = 20A
VCE = 300V
TJ = 125°C
RG = 10Ω
dV/dt < 6V/ns
1
6
0.1
0.01
3
0
0
25
50
75
100
0
100
200
300
VCE - Volts
400
500
600
Qg - nanocoulombs
Fig.11 Transient Thermal Impedance
1
D=0.5
D=0.2
D=0.1
D = Duty Cycle
0.1
D=0.05
D=0.02
D=0.01
Single Pulse
0.01
0.0001
0.001
0.01
0.1
1
10
Pulse Width - Seconds
IXSH 20N60U1
IXSH 20N60AU1
Fig.12 Maximum Forward Voltage Drop
Fig.13
Peak Forward Voltage VFR and
Forward
Recovery Time t
100
80
60
40
20
0
25
20
15
10
5
1000
fr
TJ = 125°C
IF = 37A
800
VFR
TJ = 150°C
TJ = 100°C
600
400
TJ = 25°C
200
tfr
0
0
0.5
1.0
1.5
2.0
2.5
0
100
200
300
400
500
600
Voltage Drop - Volts
diF /dt - A/µs
Fig.14Junction Temperature Dependence
off IRM and Qr
Fig.15
Reverse Recovery Chargee
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
4
3
2
1
0
TJ = 100°C
R = 350V
V
IF = 30A
max.
IRM
typ.
IF = 60A
Qr
IF = 30A
IF = 15A
0
40
80
120
160
1
10
100
1000
TJ - Degrees C
diF /dt - A/µs
Fig.16 Peak Reverse Recovery Current
Fig.17
Reverse Recovery Time
40
30
20
10
0
0.8
0.6
0.4
0.2
0.0
IF = 30A
max.
TJ = 100°C
IF = 30A
TJ = 100°C
VR = 350V
VR = 350V
max.
typ.
IF = 60A
typ.
IF = 60A
IF = 30A
IF = 15A
IF = 30A
IF = 15A
200
400
600
0
200
400
600
diF /dt - A/µs
diF /dt - A/µs
IXYSCorporation
3540 Bassett Street, Santa Clara CA 95054
Phone: 408-982-0700, Fax: 408-496-0670
IXYSSemiconductorGmbH
Edisonstr. 15, D-68623Lampertheim
Phone:+49-6206-503-0, Fax:+49-6206-503627
IXSH 20N60U1
IXSH 20N60AU1
Fig.18 Diode Transient Thermal resistance junction to case
1.00
0.10
0.01
0.001
0.01
0.1
1
Pulse Width - Seconds
