JYC0158
Page 2 of 3
Absolute Maximum Ratings at Ta = 25 ˚C
Parameter
Symbol
IF
Rating
25
Units
mA
V
Forward Current
Reverse Voltage
VR
5
Operating Temperature
Storage Temperature
Electrostatic Discharge
Power Dissipation
Topr
Tstg
-40 to +85
-40 to +90
2000
˚C
˚C
ESD
Pd
V
60
mW
Peak Forward Current
(Duty 1/10 @ 1KHz)
IFP
60
mA
Reflow Soldering: 260°C for 10 sec.
Hand Soldering: 350°C for 3 sec.
Soldering Temperature
Tsol
Electronic Optical Characteristics (Ta = 25 ˚C)
Parameter
Luminous Intensity
Viewing Angle
Symbol
Min.
15
Typ.
39
Max.
—
Units
mcd
deg
Condition
IF = 20 mA
IF = 20 mA
IV
—
130
—
2θ1/2
Peak
Wavelength
λp
—
—
—
591
589
15
—
—
—
nm
nm
nm
IF = 20 mA
IF = 20 mA
IF = 20 mA
Dominant
Wavelength
λd
Spectrum Radiation
Bandwidth
Δλ
Forward Voltage
Reverse Current
VF
IR
1.7
—
2.0
—
2.4
10
V
IF = 20 mA
VR = 5 V
μA
