R(X)A
isolated resistor networks
applications and ratings
Relative
Resistance
Tolerance
Tracking
T.C.R.
(ppm/°C)
Storage
Temperature
Range
Operating
Temperature
Range
Part
Designation
T.C.R.
(ppm/°C)
Resistance
Range
Resistance
Tolerance
B: 0.1%,C: 0.25%,
D: 0.5%,F: 1%,
G: 2%
RIA, RBA
10, 25, 50, 100*
20% ~ 0.1%
5, 10, 25, 50 -65°C to +150°C -55°C to +125°C
10Ω - 1MΩ
*For special tolerance and T.C.R. requests, please contact KOA Engineering
electrical characteristics
Package
Package Symbol
Power Rating
TSSOP
T20
1.0W
QSOP
SOIC
N14
0.6W
T16
0.8W
T24
1.0W
Q16
0.8W
Q20
Q24
1.0W
Q28
1.0W
N08
0.4W
N16
0.8W
1.0W
Resistance
Range
10Ω ~ 1kΩ
1.1kΩ
Power rating 200mW/resistor element *2
Power rating 50mW/resistor element *2
100V
Max. Working Voltage
Rated power x nominal resistance value, rated voltage should not exceed max. working voltage
+70°C
Rated Voltage
Rated Ambient Temp.
√
*2 Above rating is based on the thermal resistance using multi-layer circuit board (EIA/JESD51). For mounting on a mono-layer board,
power derating shall be needed. Total power consumption of all elements should not exceed the package power rating.
resistance ranges
Resistance Range (Ω) (E24) and Resistance Tolerance
Product
Code
Number
of Pins
T.C.R.
B: 0.1ꢀ
C: 0.2ꢁꢀ
D: 0.0ꢁꢀ
F: 1ꢀ
510 ~ 100k
510 ~ 510K
51 ~ 1M
G: 2ꢀ, J: ꢁꢀ
T: 10
E: 25
C: 50
H: 100
T: 10
8, 14, 16
20, 24
51 ~ 1M
30 ~ 1M
10 ~ 1M
RIA
510 ~ 100k
510 ~ 100k
100 ~ 200K
51 ~ 200k
30 ~ 200k
100 ~ 100k
E: 25
C: 50
H: 100
E: 25
C: 50
H: 100
51 ~ 200k
—–
10 ~ 200k
8, 14, 16,
20, 24
—–
51 ~ 200K
RBA
30 ~ 200K
10 ~ 200K
