1SS181

型号:

1SS181

描述:

低正向电压VF ( 3 ) = 0.92V (典型值)。> 快速反向恢复时间: TRR = 1.6ns (典型值)。[ Low forward voltage : VF(3)=0.92V(typ.) Fast reverse recovery time : trr=1.6ns(typ.) ]

品牌:

HTSEMI[ SHENZHEN JIN YU SEMICONDUCTOR CO., LTD. ]

页数:

2 页

PDF大小:

341 K

1SS181
SOT-23
FEATURES
y
y
Low forward voltage
: VF(3)=0.92V(typ.)
Fast reverse recovery time : trr=1.6ns(typ.)
MARKING: A3
1. CATHODE
2. CATHODE
3. ANODE
Maximum Ratings @TA=25
Parameter
Symbol
Limits
85
Unit
Non-Repetitive Peak reverse voltage
VRM
VR
V
V
80
DC Blocking
Voltage
300
Forward Continuous Current
Average Rectified Output Current
Power Dissipation
IFM
IO
mA
mA
mW
100
150
PD
125
Junction temperature
TJ
-55-125
Storage temperature range
TSTG
Electrical Characteristics @TA=25℃
Parameter
Symbol
V (BR)R
VF1
Min.
Typ.
Max. Unit
Conditions
80
Reverse Breakdown Voltage
V
V
V
IR=100μA
0.61
IF=1mA
Forward voltage
Reverse current
VF2
VF3
IR1
0.74
0.92
IF=10mA
IF=100mA
VR=30V
1.2
0.1
V
uA
0.5
4.0
IR2
CT
t r r
uA
pF
ns
VR=80V
Capacitance between terminals
Reverse recovery time
2.2
1.6
VR=0,f=1MHz
IF=IR=10mA,Irr=0.1×IR
4.0
1
JinYu
semiconductor
www.htsemi.com
Date:2011/05
1SS181
2
JinYu
semiconductor
www.htsemi.com
Date:2011/05
