Technical Information
XU 66129.00
Developmental Monolayer Adhesive Film
XU 66129.00 Developmental
Monolayer Adhesive Film is a
heat-activated, thermally stable
adhesive film capable of bonding
to urethane foam-backed fabrics,
paper, fiberglass, nonwovens, and
rigid urethanes. This thermally
activated adhesive film can be
pre-applied to foam-backed fabrics
Heat
and reactivated to bond to sub-
strates in molding operations. This
film is a high flow adhesive that is
useful for bonding substrates while
opening up for breathability and
adding stiffness to the final part.
activation point: 266°F (130°C)
Yield:
204 (sq ft/lb/mil)
(41 m2/kg/25 µm)
Available colors: Clear
Gauge range:
1.5-4.0 mil
(37.5-102 µm)
20-75 in
Width range:
(508-1905 mm)
Physical Properties
Ultimate Tensile
Test Method
ASTM D 882
ASTM D 882
ASTM D 882
ASTM D 1922
Imperial Values
@ 2.0 mil(1)
Metric Values
MD
TD
3400 psi
2600 psi
23 N/mm2
18 N/mm2
Ultimate Elongation
Tensile Modulus, 2% Secant
Elmendorf Tear
MD
TD
610 %
560 %
610 %
560 %
338 N/mm2
462 N/mm2
MD
TD
49,000 psi
67,000 psi
MD
TD
20 g/mil
80 g/mil
1 g/µm
3 g/µm
(1)Values are averages of typical film; not to be construed as specifications.
– See “Handling Considerations” reverse side.
*Trademark of The Dow Chemical Company.
Form No. 299-50172-0801 SMG
