PRODUCT FEATURE
V
SWITCH / FILTER BANK
7 CHANNELS
HARMONIC REJECTION
0.5 - 18.5 GHz (Pass Bands)
RF IN
(.5-6.0GHz)
RF IN
(5.9-18.5GHz)
HPF
HPF
• Extended Range
• Low Video Transients
• Rejection to 18.5 GHz
• Two Inputs
SP5T
SPDT
• 6 Low Pass Filters
• 3 High Pass Filters
• 4 Multi-throw Switches
• TTL Drivers
• Decoder
D
E
C
O
LPF
LPF
LPF
LPF
LPF
LPF
D
• Small Size
E
R
TTL
CH#1 CH#2 CH#3 CH#4 CH#5 CH#6
CH#7
SP5T
DRIVERS
SP3T
HPF
SPECIFICATIONS
RF OUT
(.5-18.5GHz)
(P/N 7SF8188)
PASS BANDS
0.5 - 18.5 GHz
1.0- 18.5 GHz
20 mVpp max.
5.0 dB max.
REJECTION RANGE
VIDEO TRANSIENTS
INSERTION LOSS
VSWR
FILTER CHARACTERISTICS
2.0:1 max.
PASS BAND
(GHz)
50 dB STOP
BAND (GHz)
ISOLATION
55 dB min.
+25 dBm
400 nano sec. max.
TTL 3 lines (Decoded)
175mA @+5V, 75mA @-15 V
RF OPERATING POWER
SWITCHING SPEED
CONTROL LOGIC
POWER SUPPLY
0.50 - 0.85
0.75 - 1.30
1.20 - 2.00
2.00 - 3.50
3.40 - 6.00
5.90 - 10.40
10.30 - 18.50
1.00 - 18.5
1.50 - 18.5
2.40 - 18.5
4.00 - 18.5
6.80 - 18.5
11.80 - 18.5
SIZE
CONNECTORS
OPERATING TEMPERATURE -30˚C to +85˚C
3.80" x 4.50" x 0.61"
SMA Female
