ShenzhenKYLCommunicationEquipmentCo.,Ltd
KYL-500L Special RF module for Wireless POS
Terminal
Shenzhen KYL Communication Equipment Co., Ltd
Address: C3705-3707, Huangdu Square, South of Exhibition Center, Yitian Road,
Futian District, Shenzhen, Guangdong, China 518048
Tel: 86-755-82943662
Fax: 86-755-83408785
Skype：KYL-Sunny
Yahoo messenger: KYL_Sunny@yahoo.com
MSN: KYL-Sunny@hotmail.com
Email: sales02@rf-data.com
Website: http://www.rf-data.com
1
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
Before using our products, please read the user manual carefully.
Any questions, please contact us at the above mentioned ways.
I: About KYL-500L
KYL-500L, the micro power wireless transceiver data module, is designed for
order-dish system. With small size, low power consumption as well as good
stability and reliability, it is also widely used for other embedded systems like
AMR.
II. Features of KYL-500L
1. Low power transmission: 400mW
2. Carrier frequency: 433MHz (default), 400-470MHz (optional)
3. High anti- interference and Low BER (Bit Error Rate)
Based on GFSK modulation, high-efficiency forward error correction channel
encoding technology is used to enhance the data’s resistance to both transient
interference and random interference. The actual BER can be achieved to 10-5~
10-6 when channel BER is 10-2.
4. Long Transmission Distance
Within the visible range, when the height of antenna is higher than 2m and
The BER is 10-5, the reliable transmission distance is 2km @1200bps, and is
1.5km@9600bps respectively.
5. Transparent data transmission
Transparent data interface used in transceivers is to meet many standard and
nonstandard user protocols. Any false data generated in air can be filtrated
automatically (What has been received is exactly what has been transmitted).
6. Multi-channels
We provide 8 channels, expandable for 16, 32 channels according to
requirements of customers.
7. Big data buffer area
With optional interface baud rates: 1200/4800/9600/19200bps and
8N1/8E1/8O1 data format (decide by user), the transceiver can transmit
unlimited data frames with flexible user program.
Note: the RF data rate is only settled down before delivery; please inform our
sales when placing your orders.
8. Intelligent data control system and no other extra programs required
Even for half duplex communication, no other excessive programs are required.
All RF system data transmission/reception and other On-the-Fly conversion and
control are performed by KYL-500L transceivers automatically.
9. Lower power consumption & nice sleep function
With +3.3V to 3.6 power, the receiving current is less than 25mA, the
transmitting current is less than 200mA, and the sleeping current is less than
2
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
1uA.
10. High reliability, small size and excellent performance
High sensitivity, small size is suitable for the order-dish system. With Long
transmission distance, strong penetrability, it is preferable for handheld
terminal.
III. Applications of KYL-500L
* Automatic Meter Reading (AMR)
* Wireless Dish-ordering system;
* Wireless POS, PDA, wireless smart terminals;
* Lower power consumption System;
* Wireless alarm and security systems
* Building automation, security, wireless monitor and control of room
equipment, Access Control System;
* Wireless data transmission, automatic data collection system;
* Radio modem can be used for Sports training & competition;
* Electronic bus station and intelligent traffic;
* Wireless electronic display screen and queuing machine;
* Wireless telemetry, charging for parking, parking lot;
* Automobile inspection and four-wheel orientation;
* Wireless sensor, Industrial wireless remote control and air condition remote
control;
* LED display in thruway and public place
* Point to multi-point wireless network, wireless on-the-spot bus and automatic
data collection system;
IV. How to Use KYL-500L
KYL-500L can provide RS-232, RS-485 and TTL level interface port for direct
connection with PC, RS485 devices, monolithic processors. The schematic
diagram is shown below:
1. Power supply
The factory setting is DC 3.6V. Using better ripple factor, KYL-500L transceivers
3
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
can also share power supply with other equipments. If available, a
voltage-stabilizing chip with 3.6V voltage is more recommended as the power
supplier than Switch power. But if only switch power supply available, the jam
caused by switch pulse should be avoided. In addition, a reliable grounding must be
used if there are other devices in the system. In case of failing to connect with the
ground, it can form its own grounding but must be absolutely separated from the
municipal electric supply.
2. Connection Definition with terminal
KYL-500L transceivers provide one 9-pin connector (JP1), their definitions and
connection methods with terminals are shown in Table 1.
Table 1: JP1 Pin Definitions and connection methods
Pin No. Signal Name Function
Level
Connection
with terminal
Ground
Remarks
1
2
3
4
GND
Grounding of power supply
Power supply DC
Vcc
5V
RxD/TTL
TxD/TTL
Serial data input to the transceiver
TTL
TxD
RxD
Transmitted data out of theTTL
transceiver
Signal
5
6
7
8
SGND
A (TXD)
B (RXD)
SLEEP
A of RS-485(TxD of RS-232)
B of RS-485(RxD of RS-232)
A(RxD)
B(TxD)
Sleep control (input)
Reset signal(input)
TTL
TTL
Sleep signal
High
sleep
level
9
RESET
Negative
pulse reset
3. The connection schematic diagram between computer and our RF module
4
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
4. Setting of channel, interface, and data format
Before using KYL-500L, the user needs to make simple configuration according
your own needs to determine the channel, interface mode and data format. You
can view or change the module's interface baud rate, channel and address code.
Please read or set the parameters as per the testing software KYLCOM.exe (in
products box). And the configuration is as follows:
i. Channel configuration:
Channel No.
Frequency
Channel No.
Frequency
1
2
3
4
429.0325MHZ
430.0325MHZ
431.0325MHZ
432.0325MHZ
5
6
7
8
433.0325MHZ
434.0325MHZ
435.0325MHZ
436.0325MHZ
Note: the frequency points corresponding to each channel can be adjusted
based on user’s needs.
5. Installation dimension (mm):
5
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
6. The Function-indicator light
a. The LED indicator light will turn red for 0.5S once switched on.
b. The LED indicator light will turn green continually while receiving data from
air.
c. The LED indicator light will turn red continuously when transmitting data into
air after receiving data from COM.
d. If the module moves to sleep mode, LED indicator light is always dark.
7. Supported protocol and Transmit capability
KYL-500L standard transceivers offer transparent protocol to support various
applications and protocols. If the user needs to decrease his cost or ease the
workload of terminal CPU, we can add other specific functions based on the
transparent protocol, such as addressing, data acquisition, command interpretation,
etc.
8. Sleep function instruction:
In order to reduce more consumption, KYL-500L transceivers support Sleep
function. In sleep mode, the current consumption is less than 1uA.
a. How to use the Sleep function:
The Pin8 ‘SLP’ in JP1 is the signal of sleep control. At high power level,
transceiver stays in working mode. At low power level (<0.5V), transceiver stays
in sleep mode. The SLP signal can convert transceiver from working to sleep
mode in 1ms after falling edge. If the Sleep signal arrives when the transceiver is
transmitting data, the module will enter sleep mode after finishing transmission.
From sleep mode to working, it takes the transceiver 1ms after rising edge.
To disable the opened sleep function of KYL-500L, the SLP (SLEEP) pin should
be definitely connected with 0 or ground.
b. Attentions about the use of sleep function:
When the sleep function enabled, any supply glitches, such as switch dithering,
fire striking or quick switching on and off may cause the transceiver moving to
wrong sleep mode.
Users can avoid this error by making a compulsive restoration once the CPU
6
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
delays 100ms after switching on
Sleep Timing Diagram:
9. Attentions about data transmission
a. The delay time (tc) of conversion between transmitting and receiving is less
than 1ms.
Timing diagram:
b. The delay time of transceivers between the first bit sent by TxD to the first
bit received by RxD.
As data processing happens on user’s data by KYL-500L transceiver using FEC
(Forward Error Correction) or other correction algorithm, when RxD of
KYL-500L transceiver ‘A’ receives the data, then transmits it, the other one
transceiver ‘B’ will have a delay (ts) to receive and transmit by TxD. Different
RF data rate causes different delay time. Please see the specific delay time
below:
RF Date Rate Delay
RF Date Rate Delay
(bps)
1200
Ts(mS)
90
(bps)
9600
Ts(mS)
16
7
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
2400
4800
48
19200
10
30
Timing diagram:
c. Error dealing procedure:
To enhance the reliability and stability of user’s systems, a verified bit or a
Cyclic Redundancy Check (CRC) mode is highly recommended to resist wrong
information while using KYL-500L modules.
d. Large-number data transmission
In theory, when the interface data rate is faster than the RF data rate, KYL-500L
transceivers can sent unlimited-long data package, but any long packages more
than 120B are not recommended. The length of each package should be between
60~100B. We also recommend users to resist the wrong information by using
Automatic Error Request Equipment (ARQ).
Reasons:
If the actual transmission BER (Bit Error Rate) is 10-4, 1 packet with 1KB data,
which is about 10-thousand bits, is sent, theoretically, at least 1 bit will be
received wrongly. So the 1KB information will never be received correctly.
But if we package the data into 10 packets with 100B for each, when all 10
packets are sent, there will be only 1 packet wrong according to this probability.
After that, it will resend this wrong packet using ARQ mode. So resending one
more packet and the efficiency rate is reduced 10%, all data will be absolutely
received correctly.
10. Antenna configuration:
Many appropriative antennas for low power RF modules are selected to meet
different users’ antenna configurations. Please ask our Sales for further
information about the antenna’s dimension and performance.
a. Helical SMA antennas
KYL-ANT-433-10-SMA: 100mm helical SMA antennas with high gain and low
cost, reach a long distance.
8
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
KYL-ANT-433-3-SMA: 28mm SMA helical antenna with magnetic core, small
size, beautiful appearance (like the mobile phone antenna)
KYL-ANT-433-10-ZSMA: 100mm SMA helical antenna with folding joint, easy
for adjusting the direction and fixing.
b. Magnetic vehicle antenna
KYL-ANT-O433S-300H1.5-SMA: include magnetic antenna base, suitable for
equipment with metal shell, easy for fixing, effective to enhance the transmission
distance.
For
more
kinds
of
antennas,
please
go
to
our
website:
http://www.rf-data.com/Products_list_en.asp?classid=163
If you have special demands on antennas, please specify, we can design and produce
for you individually.
V. Network Application of KYL-500L
The communication channel of KYL-500L is half duplex, which is most suitable
for the communication mode of point to multi-point. Under this mode, one master
station must be set, and all of the rest are slave stations. A unique address is given
to each station. The coordination of communication is controlled by master station
that uses data frames containing address code to transmit data or command. Slave
station will receive all of the data and command and compare the received address
code with local address code. If they are different, the data will be deserted without
9
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
ShenzhenKYLCommunicationEquipmentCo.,Ltd
any response. If those address codes are the same, it means the data is sent to the
local. Slave station will make different responses according to the transmitted data
or command and send back the data of response. All these jobs must be performed
by upper protocol, and it is assured that there is only one transmitter-receiver in the
state of transmission in the communication network at any instant moment so as to
avoid the cross-interference.
KYL-500L can also be used for point-to-point communication with easier operation.
For the programming of serial port, all you have to do is to remember that its
communication mode is semi duplex while always observing the time sequence of
come-and-go for receiving and transmitting.
VI. Technical specification of KYL-500L
* Modulation mode: GFSK/FSK
* Working frequency: 400MHz~470MHz
* Power supply: DC 3.3-3.6V（±10%）
* RF power: ≤400 mW;
* RF data rate: 1200/2400/4800/9600/19200bps (Set before delivery);
* Receive current: <25mA (TTL connect);
* Receive sensitivity: -123dBm (1200bps); -118dBm (9600bps);
* Transmitting current: <400mA;
* Sleep current: <1uA;
* Interface data format: 8E1/8N1/8O1;
* Working temperature: -40ꢀ~+80ꢀ (industrial standard)
* RF Line-of-sight Range: 1.5km (BER=10-5@9600bps);
2km(BER=10-5@1200bps)；
* Size: 49mm*23mm*10mm (without antenna port).
VII. Description of type
KYL-500L-96
Baud Rate
12:1200bps
Manufacture
Type
24:2400bps
48:4800bps
96:9600bps
192:19200bps
10
Fax: +86-755-83408785
sales02@rf-data.com
www.rf-data.com
厂商 型号 描述 页数 下载

KYL

 		KYL-200L KYL- 200L低PowerWireless收发器DataModule中[ KYL-200L Low PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200L-12 KYL- 200L低PowerWireless收发器DataModule中[ KYL-200L Low PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200L-192 KYL- 200L低PowerWireless收发器DataModule中[ KYL-200L Low PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200L-24 KYL- 200L低PowerWireless收发器DataModule中[ KYL-200L Low PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200L-48 KYL- 200L低PowerWireless收发器DataModule中[ KYL-200L Low PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200L-96 KYL- 200L低PowerWireless收发器DataModule中[ KYL-200L Low PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200L_1 低PowerWireless数据收发模块[ Low PowerWireless Transceiver Data Module ] 11 页

KYL

 		KYL-200U KYL- 200UMicro PowerWireless收发器DataModule中[ KYL-200UMicro PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200U-12 KYL- 200UMicro PowerWireless收发器DataModule中[ KYL-200UMicro PowerWireless Transceiver DataModule ] 15 页

KYL

 		KYL-200U-192 KYL- 200UMicro PowerWireless收发器DataModule中[ KYL-200UMicro PowerWireless Transceiver DataModule ] 15 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.207805s
