7. The installing schematic
8. Notice
1) The antenna should be away from the power supply if use the switch power,
because the transmitting of the antenna may affect the normal work of the switch
power. When the transmission happen fault, checking the power voltage whether
interfered from the antenna is one way of eliminating fault.
2) Use the min. grain wave and high anti-jamming switch power or batteries
3) The power capacity must meet D.C. 5~12V,more than 800mA output current
4) The space between the experiments Radio should be more than 5m. The antenna
should span on the high to increase the distance of electric wave. It is important for
using shortwave communication equipment in the city.
5) After connecting the antenna to the Radio, the space between the Radios should
more than 10m, so avoid signal backup.
6) The antenna plywood should nip in the connection inside the antenna, but
not nip the antenna projectile, so avoiding the performance of the antenna.
7) High frequency cable don’t come down directness, circle a circuit and fix up it
on the frame for the best.
9. Standard configuration and Antenna configuration
i: Standard configuration:
* One KYL-600L RF module
* A 9pin flat Connection Line
