XVC5002
• Voltage-controlled Crystal Oscillator
• Complementary PECL Output
• Enable/Disable Input
• 7.2 x 5.2 x 1.8 mm Surface-mount Case
• Complies with Directive 2002/95/EC (RoHS)
122.88 MHz
VCXO
Pb
Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
Nominal Frequency
fo
122.88
MHz
°C
°C
°C
V
Component Storage Temperature
Storage Temperature in Tape and Reel
Operating Temperature Range
Power Supply Voltage
-55
-40
+125
+85
-40
+85
Vdd
2.97
3.30
50
3.63
Load Impedance
ohm
V
Output Logic Low (“0” level)
Output Logic High (“1” level)
Duty Cycle Symmetry
Vdd - 1.810
Vdd - 1.025
45
Vdd - 1.620
Vdd - 0.880
V
55
1.0
1.0
80
%
Output Rise Time, 20% to 80% Vdd
Output Fall Time, 80% to 20% Vdd
Power Supply Current
ns
ns
Idd
mA
V
Control Voltage Input Range
Frequency Stability
Vcon
1.65 ±1.35
±50
10
ppm
ppm
ms
-
Frequency Tuning Range, 1.65 ±1.35 V
Start Up Time
1
±50
Enable Voltage Logic High
0.7 Vdd
Enable Voltage Logic Low
0.3 Vdd
1.0
-
Phase Jitter, integrated over 12 kHz to 20 MHz
Standard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization
ps
1000
5002 || YWWS
units
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1.
2.
Frequency tuning range beyond the initial tolerance at 25 °C, plus drift due to changes in temperature, power supply voltage and aging.
The design, manufacturing process, and specifications of this device are subject to change without notice.
