IXTT1N450HV

型号:

IXTT1N450HV

描述:

高压功率MOSFET[ High Voltage Power MOSFET ]

品牌:

IXYS[ IXYS CORPORATION ]

页数:

5 页

PDF大小:

156 K

Preliminary Technical Information
High Voltage
Power MOSFET
VDSS
ID25
= 4500V
= 1A
IXTT1N450HV
RDS(on) 85Ω
N-Channel Enhancement Mode
TO-268 (IXTT)
G
S
Symbol
VDSS
Test Conditions
Maximum Ratings
D (Tab)
TJ = 25°C to 150°C
TJ = 25°C to 150°C, RGS = 1MΩ
4500
4500
V
V
VDGR
G = Gate
D
= Drain
S = Source
Tab = Drain
VGSS
VGSM
Continuous
Transient
±20
±30
V
V
ID25
IDM
TC = 25°C
TC = 25°C, Pulse Width Limited by TJM
1
3
A
A
PD
TC = 25°C
520
W
TJ
TJM
Tstg
- 55 ... +150
150
- 55 ... +150
°C
°C
°C
Features
z
High Blocking Voltage
High Voltage Package
z
TL
TSOLD
Maximum Lead Temperature for Soldering
Plastic Body for 10s
300
260
°C
°C
Weight
4
g
Advantages
z
Easy to Mount
Space Savings
High Power Density
z
z
Applications
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ. Max.
z
High Voltage Power Supplies
Capacitor Discharge Applications
Pulse Circuits
Laser and X-Ray Generation Systems
z
VGS(th)
IGSS
VDS = VGS, ID = 250μA
VGS = ±20V, VDS = 0V
3.5
6.0
V
z
z
±100 nA
IDSS
VDS = 3.6kV, VGS = 0V
VDS = 4.5kV
VDS = 3.6kV
10 μA
50 μA
μA
TJ = 100°C
25
RDS(on)
VGS = 10V, ID = 50mA, Note 1
85
Ω
DS100500A(04/13)
© 2013 IXYS CORPORATION, All Rights Reserved
IXTT1N450HV
Symbol
Test Conditions
Characteristic Values
TO-268 (HV) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 50V, ID = 200mA, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
Gate Input Resistance
0.28
0.46
S
Ciss
Coss
Crss
1730
78
pF
pF
pF
28
PINS:
1 - Gate
2 - Source
3 - Drain
RGi
21
Ω
td(on)
tr
td(off)
tf
34
60
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 500V, ID = 0.5 • ID25
RG = 10Ω (External)
58
127
Qg(on)
Qgs
40
10
20
nC
nC
nC
VGS = 10V, VDS = 1kV, ID = 0.5 • ID25
Qgd
RthJC
0.24 °C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
1
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = 1A, VGS = 0V, Note 1
IF = 1A, -di/dt = 50A/μs, VR = 100V
5
2.0
V
1.75
μs
Note
1. Pulse test, t 300μs, duty cycle, d 2%.
PRELIMANARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are
derived from a subjective evaluation of the design, based upon prior knowledge and experi-
ence, and constitute a "considered reflection" of the anticipated result. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or moreof the following U.S. patents: 4,860,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463 6,771,478 B2 7,071,537
7,005,734 B2 7,157,338B2
7,063,975 B2
IXTT1N450HV
Fig. 1. Output Characteristics @ TJ = 25ºC
Fig. 2. Extended Output Characteristics @ TJ = 25ºC
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
VGS = 10V
9V
1.2
1.0
0.8
0.6
0.4
0.2
0.0
VGS = 10V
8V
8V
7V
7V
6.5V
6V
6V
0
50
100
150
200
250
300
0
0
0
10
20
30
40
50
60
70
80
VDS - Volts
VDS - Volts
Fig. 4. RDS(on) Normalized to ID = 0.5A Value vs.
Junction Temperature
Fig. 3. Output Characteristics @ TJ = 125ºC
2.6
2.2
1.8
1.4
1.0
0.6
0.2
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
VGS = 10V
7V
VGS = 10V
I D = 1A
I D = 0.5A
6V
5V
20
40
60
80
100
120
140
160
-50
-25
0
25
50
75
100
125
150
VDS - Volts
TJ - Degrees Centigrade
Fig. 6. Maximum Drain Current vs.
Case Temperature
Fig. 5. RDS(on) Normalized to ID = 0.5A Value vs.
Drain Current
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
1.0
0.8
0.6
0.4
0.2
0.0
VGS = 10V
TJ = 125ºC
TJ = 25ºC
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
1.2
-50
-25
0
25
50
75
100
125
150
TC - Degrees Centigrade
ID - Amperes
© 2013 IXYS CORPORATION, All Rights Reserved
IXTT1N450HV
Fig. 7. Input Admittance
Fig. 8. Transconductance
1.2
1.0
0.8
0.6
0.4
0.2
0.0
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
TJ = - 40ºC
25ºC
125ºC
TJ = 125ºC
25ºC
- 40ºC
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
1.1
40
VGS - Volts
ID - Amperes
Fig. 10. Gate Charge
Fig. 9. Forward Voltage Drop of Intrinsic Diode
10
9
8
7
6
5
4
3
2
1
0
3.0
2.5
2.0
1.5
1.0
0.5
0.0
VDS = 1000V
I D = 500mA
I G = 1mA
TJ = 125ºC
TJ = 25ºC
0
5
10
15
20
25
30
35
40
45
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
VSD - Volts
QG - NanoCoulombs
Fig. 12. Maximum Transient Thermal Impedance
Fig. 11. Capacitance
1
10,000
1,000
100
= 1 MHz
f
C
C
C
iss
0.1
oss
rss
0.01
10
0.0001
0.001
0.01
0.1
1
10
0
5
10
15
20
25
30
35
VDS - Volts
Pulse Width - Seconds
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXTT1N450HV
Fig. 14. Forward-Bias Safe Operating Area
Fig. 13. Forward-Bias Safe Operating Area
@ TC = 25ºC
@ TC = 75ºC
10
10
RDS(on) Limit
RDS(on) Limit
25µs
100µs
25µs
1
1
100µs
1ms
1ms
10ms
10ms
0.1
0.1
100ms
100ms
DC
TJ = 150ºC
C = 25ºC
Single Pulse
TJ = 150ºC
C = 75ºC
Single Pulse
DC
T
T
0.01
100
0.01
100
1,000
10,000
1,000
10,000
VDS - Volts
VDS - Volts
© 2013 IXYS CORPORATION, All Rights Reserved
IXYS REF: T_1N450(H7)10-09-12
