IXTP02N120P
IXTY02N120P
Symbol
Test Conditions
Characteristic Values
TO-220 (IXTP) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 30V, ID = 0.5 • ID25, Note 1
0.12
0.20
S
Ciss
Coss
Crss
104
8.6
1.9
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
6
10
21
39
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 60V, ID = 0.5 • ID25
,
RG = 50Ω (External)
Qg(on)
Qgs
Qgd
4.70
0.37
3.20
nC
nC
nC
VGS= 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Pins: 1 - Gate
2 - Drain
RthJC
RthCS
3.8 °C/W
°C/W
TO-220
0.50
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
0.2
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
0.8
1.3
trr
IRM
QRM
1.6
3.5
2.8
μs
A
μC
IF = 0.2A, -di/dt = 50A/μs,
VR = 100V, VGS = 0V
TO-252 (IXTY) Outline
Pins: 1 - Gate
3 - Source
2,4 - Drain
Note 1: Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
Dim. Millimeter
Min. Max.
Inches
Min.
Max.
A
A1
2.19 2.38
0.89 1.14
0.086
0.035
0.094
0.045
A2
b
0
0.13
0
0.005
0.035
0.64 0.89
0.025
b1
b2
0.76 1.14
5.21 5.46
0.030
0.205
0.045
0.215
