Preliminary
XVT9009
• Voltage Controlled Temperature Compensated Crystal Oscillator
• Excellent Frequency Stability & Low Phase Noise
• 7 x 5 x 2 mm Surface-Mount Case
• Complies with Directive 2002/95/EC (RoHS)
20 MHz
VCTCXO
Pb
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
MHz
°C
Nominal Frequency
Fo
20.000000
Storage Temperature
-55
-40
+125
+85
Operating Temperature Range
Power Supply Voltage
°C
V
2.97
1.0
3.30
3.63
V
DD
V
V
Output Voltage with Load 10 pF||10 KΩ
Output Wave form
OUT
P-P
Sinewave
1.65 ±1.0
I
Power Supply Current
8.0
mA
V
DD
V
Control Voltage
CON
Control Voltage Input Impedance
100K
ohms
Frequency Tolerance, V
=1.65 V (as received)
±2.0 ppm maximum @ 25 °C ±3 °C
CONTROL
Frequency Stability versus:
Temperature, -40 to 85 °C
Supply Voltage, 2.97 to 3.63 V
Load, 10 pF||10 KΩ ±10%
±0.5
±0.2
±0.2
±5
ppm
ppm
ppm
ppm
ms
Control Voltage Frequency Range (1.65 ±1.0 V)
Start Up Time, 90% of final RF level in V
2.0
P-P
First Year Aging @ 25 °C
10 Year Aging @ 25 °C
Harmonics
±1
ppm
ppm
dBc
±5
-5.0
SSB Phase Noise:
@ 1 kHz Carrier Offset
@ 10 kHz Carrier Offset
@ 100 kHz Carrier Offset
Stanard Shipping Quantity on 180 mm (7”) Reel
Lid Symbolization
-135
-145
dBc/Hz
dBc/Hz
dBc/Hz
units
-150
500
9009 // YWWS
