IXTA80N10T
IXTP80N10T
Symbol
Test Conditions
Characteristic Values
TO-263 (IXTA) Outline
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
33
55
S
Ciss
Coss
Crss
3040
420
90
pF
pF
pF
td(on)
tr
td(off)
tf
31
54
40
48
ns
ns
ns
ns
1. Gate
2. Drain
3. Source
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 10A
RG = 15Ω (External)
Qg(on)
Qgs
60
21
15
nC
nC
nC
Dim.
Millimeter
Inches
Min. Max.
VGS = 10V, VDS = 0.5 • VDSS, ID = 25A
Min.
Max.
A
b
b2
4.06
0.51
1.14
4.83
0.99
1.40
.160
.020
.045
.190
.039
.055
Qgd
RthJC
RthCS
0.65 °C/W
°C/W
c
c2
0.40
1.14
0.74
1.40
.016
.045
.029
.055
0.50
D
D1
8.64
8.00
9.65
8.89
.340
.280
.380
.320
E
9.65
10.41
.380
.405
E1
e
L
L1
L2
L3
L4
6.22
2.54
14.61
2.29
1.02
1.27
0
8.13
BSC
15.88
2.79
1.40
1.78
0.13
.270
.100 BSC
.320
.575
.090
.040
.050
0
.625
.110
.055
.070
.005
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
TO-220 (IXTP) Outline
IS
VGS = 0V
80
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = 25A, VGS = 0V, Note 1
220
1.1
V
100
ns
IF = 25A, -di/dt = 100A/μs
VR = 50V, VGS = 0V
Pins:
1 - Gate
3 - Source
2 - Drain
4 - Drain
Notes 1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
2. On through-kole packages RDS(on) Kelvin test contact location
must be 5 mm or less from the package body.
