IXTA10P50P IXTQ10P50P
IXTP10P50P IXTH10P50P
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = -10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = - 25V, f = 1MHz
6.5
11
S
Ciss
Coss
Crss
2840
275
42
pF
pF
pF
td(on)
tr
td(off)
tf
20
28
52
44
ns
ns
ns
ns
Resistive Switching Times
VGS = -10V, VDS = 0.5 • VDSS, ID = 0 .5 • ID25
RG = 3.3Ω (External)
Qg(on)
Qgs
50
17
18
nC
nC
nC
VGS = -10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.42 °C/W
°C/W
(TO-3P & TO-247)
(TO-220)
0.25
0.50
°C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
- 10
- 40
- 3
IS
VGS = 0V
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = - 5A, VGS = 0V, Note 1
trr
QRM
IRM
414
5.90
- 28.6
ns
μC
A
IF = - 5A, -di/dt = -100A/μs
VR = -100V, VGS = 0V
Note
1: Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
