IXTF1N450

型号:

IXTF1N450

描述:

高压功率MOSFET[ High Voltage Power MOSFET ]

品牌:

IXYS[ IXYS CORPORATION ]

页数:

5 页

PDF大小:

158 K

Preliminary Technical Information
High Voltage
Power MOSFET
VDSS
ID25
= 4500V
= 0.9A
IXTF1N450
RDS(on) 95Ω
(Electrically Isolated Tab)
ISOPLUS i4-PakTM
N-Channel Enhancement Mode
Symbol
VDSS
Test Conditions
Maximum Ratings
1
2
Isolated Tab
TJ = 25°C to 150°C
TJ = 25°C to 150°C, RGS = 1MΩ
4500
4500
V
V
5
VDGR
VGSS
VGSM
Continuous
Transient
±20
±30
V
V
1 = Gate
2 = Source
5 = Drain
ID25
IDM
TC = 25°C
TC = 25°C, Pulse Width Limited by TJM
0.9
3.0
A
A
PD
TC = 25°C
165
W
Features
TJ
TJM
Tstg
- 55 ... +150
150
- 55 ... +150
°C
°C
°C
z
Silicon Chip on Direct-Copper Bond
(DCB) Substrate
Isolated Mounting Surface
4500V~ Electrical Isolation
Molding Epoxies meet UL 94 V-0
Flammability Classification
z
z
z
TL
TSOLD
Maximum Lead Temperature for Soldering
Plastic Body for 10s
300
260
°C
°C
FC
Mounting Force
20..120 / 4.5..27
N/lb.
V~
g
VISOL
Weight
50/60Hz, 1 Minute
4500
6
Advantages
z
High Voltage Package
Easy to Mount
Space Savings
High Power Density
z
z
z
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ. Max.
Applications
VGS(th)
IGSS
VDS = VGS, ID = 250μA
VGS = ±20V, VDS = 0V
3.5
6.0
V
z
High Voltage Power Supplies
Capacitor Discharge Applications
Pulse Circuits
±100 nA
z
z
IDSS
VDS = 3.6kV, VGS = 0V
VDS = 4.5kV
10 μA
50 μA
μA
z
Laser and X-Ray Generation Systems
VDS = 3.6kV
Note 2, TJ = 100°C
25
RDS(on)
VGS = 10V, ID = 50mA, Note 1
95
Ω
DS100501B(04/13)
© 2013 IXYS CORPORATION, All Rights Reserved
IXTF1N450
Symbol
Test Conditions
Characteristic Values
ISOPLUS i4-PakTM (HV) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 50V, ID = 200mA, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
Gate Input Resistance
0.28
0.46
S
Ciss
Coss
Crss
1730
78
pF
pF
pF
28
RGi
21
Ω
td(on)
tr
td(off)
tf
34
60
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 500V, ID = 0.5A
RG = 10Ω (External)
58
127
Pin 1 = Gate
Pin 2 = Soure
Pin 3 = Drain
Pin 4 = Isolated
Qg(on)
Qgs
40
10
20
nC
nC
nC
VGS = 10V, VDS = 1kV, ID = 0.5A
Qgd
RthJC
RthCS
0.77 °C/W
°C/W
0.15
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
1
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = 1A, VGS = 0V, Note 1
IF = 1A, -di/dt = 50A/μs, VR = 100V
5
2.0
V
1.75
μs
Notes: 1. Pulse test, t 300μs, duty cycle, d 2%.
2. Part must be heatsunk for high-temp IDSS measurement.
PRELIMINARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from data gathered during objective characterizations of preliminary engineering lots; but also may yet
contain some information supplied during a pre-production design evaluation. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or moreof the following U.S. patents: 4,860,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
IXTF1N450
Fig. 1. Output Characteristics @ TJ = 25ºC
Fig. 2. Extended Output Characteristics @ TJ = 25ºC
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
VGS = 10V
9V
1.2
1.0
0.8
0.6
0.4
0.2
0.0
VGS = 10V
8V
8V
7V
7V
6.5V
6V
6V
0
50
100
150
200
250
300
0
10
20
30
40
50
60
70
80
VDS - Volts
VDS - Volts
Fig. 4. RDS(on) Normalized to ID = 0.5A Value vs.
Junction Temperature
Fig. 3. Output Characteristics @ TJ = 125ºC
2.6
2.2
1.8
1.4
1.0
0.6
0.2
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
VGS = 10V
7V
VGS = 10V
I D = 1A
I D = 0.5A
6V
5V
0
20
40
60
80
100
120
140
160
-50
-25
0
25
50
75
100
125
150
VDS - Volts
TJ - Degrees Centigrade
Fig. 6. Maximum Drain Current vs.
Case Temperature
Fig. 5. RDS(on) Normalized to ID = 0.5A Value vs.
Drain Current
1.0
0.8
0.6
0.4
0.2
0.0
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
VGS = 10V
TJ = 125ºC
TJ = 25ºC
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
1.2
-50
-25
0
25
50
75
100
125
150
TC - Degrees Centigrade
ID - Amperes
© 2013 IXYS CORPORATION, All Rights Reserved
IXTF1N450
Fig. 7. Input Admittance
Fig. 8. Transconductance
1.2
1.0
0.8
0.6
0.4
0.2
0.0
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
TJ = - 40ºC
25ºC
125ºC
TJ = 125ºC
25ºC
- 40ºC
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
1.1
40
VGS - Volts
ID - Amperes
Fig. 10. Gate Charge
Fig. 9. Forward Voltage Drop of Intrinsic Diode
10
9
8
7
6
5
4
3
2
1
0
3.0
2.5
2.0
1.5
1.0
0.5
0.0
VDS = 1000V
I D = 500mA
I G = 1mA
TJ = 125ºC
TJ = 25ºC
0
5
10
15
20
25
30
35
40
45
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
VSD - Volts
QG - NanoCoulombs
Fig. 12. Forward-Bias Safe Operating Area
Fig. 11. Capacitance
10.00
1.00
0.10
0.01
10,000
1,000
100
= 1 MHz
f
RDS(on) Limit
25µs
100µs
C
C
C
iss
1ms
oss
rss
10ms
TJ = 150ºC
TC = 25ºC
Single Pulse
10
100
1,000
10,000
0
5
10
15
20
25
30
35
VDS - Volts
VDS - Volts
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXTF1N450
Fig. 13. Maximum Transient Thermal Impedance
1
0.1
0.01
0.0001
0.001
0.01
0.1
1
10
100
Pulse Width - Seconds
© 2013 IXYS CORPORATION, All Rights Reserved
IXYS REF: T_1N450(H7)10-09-12
