Optical Jumper Cable
JUMP Series
Product Description
Oplink’s Optical Jumper Cable is designed for interconnection
for all optical systems or components. Oplink offer a wide range
of industrial standard jumper cables with various fiber and fiber
jacket types, connectors, and lengths.With our highly integrated
design and manufacturing capability, Oplink can also provide cus-
tomized products to help our customer for better opportunities.
Our jumper cable complies with industry green initiative such as
Rohs.
Features
Applications
Various Option of fiber and connector types and lengths
Environmental Green Plan Compliance
High Reliability and Stability
Optical System Access Network
System interconnection
Premium Optical Connector
100% Ferrule Turning to minimize Insertion Loss
100% DORC Test
Product Specifications
S Grade
(Low Loss)
P Grade
(Standard)
Parameters
Unit.
Single-Mode
Operating Wavelength
1260 ~ 1620
850 & 1310
nm
Multi-Mode
Single-Mode
Insertion Loss (PC/UPC Type)
Multi-Mode*
0.15
0.25
0.30
0.30
dB
dB
Insertion Loss (APC Type)
Single-Mode
Single-Mode PC Type
Single-Mode UPC Type
Single-Mode APC Type
Multi-Mode
45
50
Return Loss
dB
60
35
Connection Durability
Connector Repeatability
Operating Temperature
500
mating
dB
0.2
-20 ~ 70
SMF-28
°C
Single Mode Fiber
Multi Mode Fiber
Fiber Type
50/125 µm
62.5/125 µm
Note:
1)
Tested at 1310nm and 1550nm for single-mode jumper, 850nm and 1310nm for multi-mode jumper..
2) *: For jumper length less than 5 meter. Additional 0.03dB for every 10 meters within 850nm window, and 0.01dB for 1310nm window.
S0021 - R05. 20111014
